Categories

Tower Sites

XD Series™ V-Frames

SKU	Face Width	Antenna Pipe Hardware For	Stiff Arm Qty.	Mounts to Leg Sizes	Weight
VFA8-XDS Details & Purchase	9'	3 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	656 lbs
VFA8-XD Details & Purchase	9'	3 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	750 lbs
VFA10-XDS Details & Purchase	11’	4 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	705 lbs
VFA10-XD Details & Purchase	11’	4 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	798 lbs
VFA12-XDS Details & Purchase	13’	4 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	729 lbs
VFA12-XD Details & Purchase	13’	4 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	823 lbs
VFA14-XDS Details & Purchase	15’	4 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	743 lbs
VFA14-XD Details & Purchase	15’	4 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	837 lbs

HD Series™ V-Frames

SKU	Face Width	Antenna Pipe Hardware For	Stiff Arm Qty.	Mounts to Leg Sizes	Weight
VFA6-HD-S Details & Purchase	7'	2 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	522 lbs
VFA6-HD Details & Purchase	7'	2 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	507 lbs
VFA8-HD-S Details & Purchase	9'	3 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	552 lbs
VFA8-HD Details & Purchase	9'	3 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	595 lbs
VFA10-HD-S Details & Purchase	11'	4 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	590 lbs
VFA10-HD Details & Purchase	11'	4 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	631 lbs
VFA12-HD-S Details & Purchase	13'	4 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	595 lbs
VFA12-HD Details & Purchase	13'	4 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	760 lbs
VFA14-HD Details & Purchase	15'	4 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	646 lbs

SD Series™ V-Frames

SKU	Face Width	Antenna Pipe Hardware For	Stiff Arm Qty.	Mounts to Leg Sizes	Weight
VFA6-SD-S Details & Purchase	7'	2 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	366 lbs
VFA6-SD Details & Purchase	7'	2 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	441 lbs
VFA8-SD-S Details & Purchase	9'	3 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	472 lbs
VFA8-SD Details & Purchase	9'	3 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	472 lbs
VFA10-SD-S Details & Purchase	11'	4 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	460 lbs
VFA10-SD Details & Purchase	11'	4 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	498 lbs
VFA12-SD-S Details & Purchase	13'	4 Pipes (Sold Separately)	1	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	426 lbs
VFA12-SD Details & Purchase	13'	4 Pipes (Sold Separately)	2	1-1/2" to 9-1/2" Round Legs and 3" to 6" Angles	509 lbs

10' HD Series™ V-Frames (3 Sector Kit)

SKU	Face Width	Ant. Pipe Qty.	Ant. Pipe OD	Ant. Pipe Length	TB Qty.	RRU Pipe Qty.	RRU Pipe OD	RRU Pipe Length	Weight
3VFA10HDT3010R2 Details	11'-0"	12	2.875"	120"	6	6	2.375"	72"	0 lbs

12' HD Series™ V-Frames (3 Sector Kit)

SKU	Face Width	Ant. Pipe Qty.	Ant. Pipe OD	Ant. Pipe Length	TB Qty.	RRU Pipe Qty.	RRU Pipe OD	RRU Pipe Length	Weight
3VFA12HDT3010R2 Details	13"-0'	12	2.875"	120"	6	6	2.375"	72"	3,169 lbs

Full Universal RRU Mount

SKU	Description	Weight
RRU-FU2 Details & Purchase	Universal RRU Mount	50.39 lbs

Dual RRU Swivel Mount Kit

SKU	Mounting Range	Weight
RRUDSM Details & Purchase	Pipes up to 4-1/2”; Angles up to 3” x 3”	41 lbs

Dual RRU Swiveling Tower Mount

SKU	Mounting Range	Weight
RRUDPMX Details & Purchase	Pipes up to 4-1/2”; Angles up to 3” x 3”	122 lbs

Ultimate Stand-Off Frame

SKU	Stand-Off	Weight
USF-2U Details & Purchase	24''	125 lbs
USF-3U Details & Purchase	36''	141.51 lbs

Universal Tapered Pipe Mount

SKU	Pipe Size	Stand-Off	Weight
ADP238-U Details & Purchase	2-3/8” x 63”	14”	114.9 lbs
ADP-U Details & Purchase	4-1/2” x 63”	15-1/2”	118.22 lbs

Sliding Universal Tapered Pipe Mounts

SKU	Pipe OD	Stand-Off	Weight
TAM-2U Details & Purchase	2-3/8” and 2-7/8”	1'	85.2 lbs
TAM-2U-L Details & Purchase	2-3/8” and 2-7/8”	2'	115 lbs
TAM-3U Details & Purchase	3-1/2” and 4-1/2”	1'	100 lbs
TAM-3U-L Details & Purchase	3-1/2” and 4-1/2”	2'	115 lbs

Compact Tower Mounts

SKU	Leg Size	Weight
CWT01 Details & Purchase	Round legs 1-1/2” to 4-1/2”Angle legs up to 3”	123 lbs

R5 Standard-Duty Universal Pipe Mount Kit

SKU	Pipe	Mounts to Leg Sizes	Weight
R5 Details & Purchase	4-1/2” x 72”	1-1/2" to 4-1/2" O.D.	144 lbs
R5-LL Details & Purchase	4-1/2” x 72”	Tubular legs 5" to 14" and angle legs 3" to 8"	250 lbs
R5-UP Details & Purchase	No Pipe Included; Accepts Antenna Mounting Pipes 1-1/2” to 4-1/2”	Tubular legs 1-1/2" to 4-1/2"	80 lbs

R5-216 Heavy-Duty Universal Pipe Mount Kit

SKU	Pipe OD	Stand-Off	Mount Pipe	Weight
R5-216 Details & Purchase	1-1/2” to 4-1/2”	18”	4-1/2” x 72”	235 lbs

R6 Heavy-Duty Universal Pipe Mount Kit

SKU	Pipe	Mounts to Leg Sizes	Weight
R6 Details & Purchase	4-1/2” x 72”	Tubular legs 1-1/2” to 9-1/2” and angle legs 3" to 6"	263.03 lbs

Universal Tubular-Arm Pipe Mounts

SKU	Weight
TAP-472 Details & Purchase	240 lbs
TAP-NP Details & Purchase	177 lbs
TAP-PM Details & Purchase	32 lbs
TAP-LM Details & Purchase	67.85 lbs

Universal Face Pipe Mount Assembly

SKU	Sectors	Face Pipes	Weight
FACE-ASY1-30126 Details & Purchase	One	(2) 2-7/8” x 11'	660 lbs
FACE-ASY1-3126 Details & Purchase	One	(2) 3-1/2” x 11'	690 lbs
FACE-ASY1-4126 Details & Purchase	One	(2) 4-1/2” x 11'	755 lbs
FACE-ASY1-NP Details & Purchase	One	None	530 lbs
FACE-ASY3-30126 Details & Purchase	Three	(6) 2-7/8" x 11'	1,236 lbs
FACE-ASY3-3126 Details & Purchase	Three	(6) 3-1/2” x 11'	1,327 lbs
FACE-ASY3-4126 Details & Purchase	Three	(6) 4-1/2” x 11'	1,530 lbs
FACE-ASY3-NP Details & Purchase	Three	None	850 lbs
FACE-ASY4-30126 Details & Purchase	Four	(8) 2-7/8" x 11'	1,651 lbs
FACE-ASY4-3126 Details & Purchase	Four	(8) 3-1/2” x 11'	1,772 lbs
FACE-ASY4-4126 Details & Purchase	Four	(8) 4-1/2” x 11'	2,043 lbs
FACE-ASY4-NP Details & Purchase	Four	None	1,134 lbs

Universal Adjustable Slope Pipe Mount

SKU	Pipe Size	Weight
UAS60 Details	4-1/2” x 60”	242 lbs

Panel Antenna Stand-Off Mounts

SKU	Stand-Off	Antenna Pipe Size	Mounting Pipe Size	Pipe Diameter	Weight
PM1 Details & Purchase	1’	120"	60”	2-3/8” OD	60 lbs
PM2 Details & Purchase	2’	120”	60"	2-3/8” OD	68 lbs
PM1-278 Details & Purchase	1’	120"	60”	2-7/8” OD	100 lbs

Lightweight Stand-Off Mounts

SKU	Stand-Off	Mast Pipe	Weight
S2-K Details & Purchase	2'	24"	26 lbs
S3-K Details & Purchase	3'	24"	30 lbs
S4-K Details & Purchase	4'	38"	42 lbs

Stand-Off Mounts (Universal Kit)

SKU	Stand-Off	Mast Size	Stiff-Arm Qty.	Weight
HS4-K Details & Purchase	4'	2-3/8” x 38”	1	245 lbs

Stand-Off Pipe Mounts

SKU	Stand-Off	Stiff-Arm Qty.	Weight
PSA3 Details & Purchase	3'	1	120 lbs
PSA6 Details & Purchase	6'	1	182 lbs

Universal Side-Arm Mount

SKU	Weight
USA3 Details & Purchase	61 lbs

Pipe V-Style Sector Frame Stabilizer Kits

SKU	Stabilizer Direction	Stabilizer Material	Stand-Off Distance	Weight
VSK-TH Details & Purchase	Horizontal	Pipe	24” to 36”	98 lbs
VSK-TH-L Details & Purchase	Horizontal	Pipe	36” to 48”	120 lbs
VSK-TV Details & Purchase	Vertical	Pipe	24” to 36”	100 lbs
VSK-TV-L Details & Purchase	Vertical	Pipe	36” to 48”	118 lbs

Pipe V-Style Sector Frame Reinforcement Kits

SKU	Stabilizer Direction	Stand-Off Distance	Weight
VSK-SFR Details & Purchase	Horizontal and Vertical	24” to 36”	200 lbs
VSK-SFR-L Details & Purchase	Horizontal and Vertical	36” to 48”	236 lbs

Angle Sector Frame Stabilizer Kits

SKU	Stabilizer Direction	Stabilizer Material	Stand-Off Distance	Weight
SFS-H Details & Purchase	Horizontal	Angle	24” to 36”	67 lbs
SFS-H-L Details & Purchase	Horizontal	Angle	36” to 48”	77 lbs
SFS-V Details & Purchase	Vertical	Angle	24” to 36”	66 lbs
SFS-V-L Details & Purchase	Vertical	Angle	36” to 48”	77 lbs

Angle Sector Frame Reinforcement Kits

SKU	Stabilizer Direction	Stand-Off Distance	Weight
SFR-K Details & Purchase	Horizontal and Vertical	24” to 36”	132 lbs
SFR-K-L Details & Purchase	Horizontal and Vertical	36” to 48”	153 lbs

Tube Reinforcement Kit

SKU	Sectors	Horizontal Connection	Angle SIze	Weight
PRK-FMA Details & Purchase	3	5” x 5” Max	2L 2-1/2” x 2-1/2” x 3/16” x 84”	330 lbs
PRK-FMA1 Details & Purchase	1	5” x 5” Max	2L 2-1/2” x 2-1/2” x 3/16” x 84”	110 lbs
PRK-FMA-NA Details & Purchase	3	5” x 5” Max	Order Separately	330 lbs

BCAM™ Large Leg HD Adapter Kits

SKU	Description	Weight
BCAM-HDLL Details & Purchase	Attaches to #12 breakdown legs	134 lbs
BCAM-HDLL-AA Details & Purchase	Attaches to 7" to 12" 90° angle legs or #12 breakdown legs	131 lbs

BCAM™ Large Leg SD Adapter Kits

SKU	Attaches to	Weight
BCAM-SDLL Details & Purchase	#12 breakdown legs	114 lbs
BCAM-SDLL-AA Details & Purchase	7" to 12" 90° angle legs or #12 breakdown legs	115 lbs

Universal Sliding Pipe Stiff Arm Assemblies

SKU	Outer Diameter (OD)	Length	Weight
SPTB-U Details	2-3/8"	120"	89 lbs
SPTB-U-F Details	N/A	N/A	16 lbs
SPTB-U-NP Details & Purchase	N/A	N/A	53 lbs

Sector Frame Stiff Arm Kits

SKU	Pipe	Weight
STK-U Details & Purchase	Light Duty 2-3/8” x 120” Stiff Arm	56 lbs
STK-U-NP Details & Purchase	No Pipe Included	16 lbs

Universal Stiff Arm Leg Attachment Kits

SKU	Application	Stiff Arm Size	Weight
SPTB-U-B Details	1-1/2" to 8-5/8" Round, 1-1/2" to 8-1/2" 60° Angles, 1-1/2" to 6" 90° Angles	2-3/8" OD	26 lbs
SAM-U Details & Purchase	1" to 6" Round, 1" to 6" 60° Angles, 1" to 4" 90° Angles	2-3/8" OD	8.08 lbs

Adjustable Clamp Plate Assembly

SKU	Application	Weight
PUCK Details & Purchase	7/8" to 3-1/2" OD	6 lbs

Large Leg Adapter Kit for Tower Mounts & Reinforcement Kits

SKU	Weight
TAM-LL Details & Purchase	38.55 lbs

Large Leg Adapter Kit for Tower Mounts

SKU	Weight
LLEG-K Details & Purchase	74 lbs

Large Leg Adapter FACE Kit

SKU	Sectors	Face Pipes	Weight
FACE-LLEG Details & Purchase	Varies	None	76 lbs

Pipe Mount Attachment Kit

SKU	Description	Weight
FACE-PM Details & Purchase	Pipe Mount Attachment Kit for Face Mount	51.13 lbs

Wide V-Clamp™ Series Tower Leg Hangers

SKU	# of Tabs	# of Shackles	Weight
CHB-DVC4 Details & Purchase	4	4	19.5 lbs

Universal Tri-Sector Mount Kit

SKU	Weight
UTSM Details & Purchase	48 lbs
UTSM-L Details & Purchase	46 lbs

Double Antenna Clamp

SKU	Qty.	Weight
DAC Details & Purchase	Kit of 2	25 lbs

Universal GPS Mount

SKU	Pipe Size	Weight
GPSP Details & Purchase	1.90'' x 2'	16 lbs

TMA Bracket

SKU	Weight
PB-TMA-K Details & Purchase	6.7 lbs

Pipe Mount Extension for Ice Shields

SKU	Weight
PME2 Details & Purchase	36.8 lbs

Mini Ice Shield

SKU	Size	Weight
MIS-24 Details & Purchase	24” x 24”	70 lbs

Microwave Ice Shields

SKU	Antenna Diameter	Size	Weight
ISMD4 Details & Purchase	4’	48” x 62”	325 lbs
ISMD6 Details & Purchase	6’	72” x 62”	365 lbs
ISMD8 Details & Purchase	8’	96” x 62”	445 lbs

Curved Ice Shield

SKU	Antenna Diameter	Weight
CIS04 Details & Purchase	4'	580 lbs
CIS06 Details & Purchase	6'	740 lbs

Cable Ladders

SKU	Number of Runs	Length	Width	Weight
WCL4 Details & Purchase	4	20'	14"	110 lbs
WCL6 Details & Purchase	6	20'	20-5/8”	119 lbs
WCL9 Details & Purchase	9	20'	29-5/8”	80 lbs
WCL12 Details & Purchase	12	20'	38-5/8”	130 lbs

Universal Ladder Attachment Kit

SKU	Weight
CLK-U Details & Purchase	4.3 lbs

Monopole Sites

Fortress FlexMax™ Tri-Platform Mounts

SKU	Pole Diameter	Pole Circumference	Face Width	Weight
FX3P-8W Details & Purchase	14" - 30"	44" - 94.25"	9'	2,030.97 lbs
FX3P-10W Details & Purchase	14" - 36"	44" - 113"	11'	2,030.97 lbs
FX3P-12W Details & Purchase	14" - 44"	44" - 138"	13'	2,212.35 lbs
FX3P-14W Details & Purchase	14" - 44"	44" - 138"	15'	2,420.53 lbs

Fortress FlexMax™ Quad-Platform Mounts

SKU	Pole Diameter	Pole Circumference	Face Width	Weight
FX4P-8W Details & Purchase	14” - 30”	44” - 94.25”	9’	2,708 lbs
FX4P-10W Details & Purchase	14" - 51"	44" - 160"	11'	2,708 lbs
FX4P-12W Details & Purchase	14" - 65"	44" - 204"	13'	2,950 lbs
FX4P-14W Details & Purchase	14" - 44"	44" - 138"	15'	3,228 lbs

Platform RRU Mounting Kit

SKU	Description	Weight
SAMAST-3 Details & Purchase	3’ Platform RRU Mount	29 lbs
SAMAST-6 Details & Purchase	6’ Platform RRU Mount	45 lbs

Low-Profile Platforms (9 Antennas)

SKU	Antennas	Pole Diameter	Pole Circumference	Face Width	Mounting Pipes	Weight
RMQP-NP Details & Purchase	N/A	12” - 38”	37.7” - 119.3”	13'	N/A	650 lbs
RMQP-372 Details & Purchase	9	12” - 38”	37.7” - 119.3”	13'	(9) 2-3/8” x 72”	1,600 lbs
RMQP-396 Details & Purchase	9	12” - 38”	37.7” - 119.3”	13'	(9) 2-3/8” x 96”	1,670 lbs
RMQP-3126 Details & Purchase	9	12” - 38”	37.7” - 119.3”	13'	(9) 2-3/8” x 120”	1,750 lbs
RMQLP-NP Details & Purchase	N/A	12” - 38”	37.7” - 119.3”	15'	N/A	1,310 lbs
RMQLP-396 Details & Purchase	9	12” - 38”	37.7” - 119.3”	15'	(9) 2-3/8” x 96”	1,765 lbs
RMQLP-3126 Details & Purchase	9	12” - 38”	37.7” - 119.3”	15'	(9) 2-3/8” x 120”	1,985 lbs
RMVP-NP Details & Purchase	N/A	30” - 60”	94.2” - 188.4”	15'	N/A	1,475 lbs
RMVP-396 Details & Purchase	9	30” - 60”	94.2” - 188.4”	15'	(9) 2-3/8” x 96”	2,540 lbs
RMVP-3126 Details & Purchase	9	30” - 60”	94.2” - 188.4”	15'	(9) 2-3/8” x 120”	1,830 lbs

Low-Profile Platforms (12 Antennas)

SKU	Antennas	Pole Diameter	Pole Circumference	Face Width	Mounting Pipes	Weight
RMQP-472 Details & Purchase	12	12” - 38”	37.7” - 119.3”	13'	(12) 2-3/8'' x 72''	1,705 lbs
RMQP-496 Details & Purchase	12	12” - 38”	37.7” - 119.3”	13'	(12) 2-3/8” x 96”	1,900 lbs
RMQP-4126 Details & Purchase	12	12” - 38”	37.7” - 119.3”	13'	(12) 2-3/8” x 120”	1,980 lbs
RMQLP-496 Details & Purchase	12	12” - 38”	37.7” - 119.3”	15'	(12) 2-3/8” x 96”	1,905 lbs
RMQLP-4126 Details & Purchase	12	12” - 38”	37.7” - 119.3”	15'	(12) 2-3/8” x 120”	1,985 lbs
RMVP-496 Details & Purchase	12	30” - 60”	94.2” - 188.4”	15'	(12) 2-3/8” x 96”	2,675 lbs
RMVP-4126 Details & Purchase	12	30” - 60”	94.2” - 188.4”	15'	(12) 2-3/8” x 120”	1,990 lbs

Low-Profile Platforms w/ Kickers (12 Antennas)

SKU	Pole Diameter	Pole Circumference	Face Width	Mounting Pipes	Weight
RMQP-496-HK Details & Purchase	12” - 38”	37.7” - 119.3”	13'	(12) 2-3/8” x 96”	2,449 lbs
RMQP-4096-HK Details & Purchase	12” - 38”	37.7” - 119.3”	13'	(12) 2-7/8” x 96”	2,650 lbs
RMQP-4126-HK Details & Purchase	12” - 38”	37.7” - 119.3”	13'	(12) 2-3/8” x 120”	2,700 lbs
RMQLP-496-HK Details & Purchase	12” - 38”	37.7” - 119.3”	15'	(12) 2-3/8” x 96”	2,448 lbs
RMQLP-4096-HK Details & Purchase	12” - 38”	37.7” - 119.3”	15'	(12) 2-7/8” x 96”	2,810 lbs
RMQLP-4126-HK Details & Purchase	12” - 38”	37.7” - 119.3”	15'	(12) 2-3/8” x 120”	2,600 lbs
RMVP-496-HK Details & Purchase	30” - 60”	94.2” - 188.4”	15'	(12) 2-3/8” x 96”	2,517 lbs
RMVP-4096-HK Details & Purchase	30” - 60”	94.2” - 188.4”	15'	(12) 2-7/8” x 96”	2,780 lbs
RMVP-4126-HK Details & Purchase	30” - 60”	94.2” - 188.4”	15'	(12) 2-3/8” x 120”	2,700 lbs

Magnum™ Snub-Nose Platform Kit

SKU	Pole Diameter	Pole Circumference	Face Width	Mounting Pipes	Weight
SNP8-NP Details & Purchase	12'' - 45''	37.7” - 141.3”	9’	None	1,240.46 lbs
SNP8-396 Details & Purchase	12” - 45”	37.7” - 141.3”	9’	(9) 2-3/8” x 96”	1,463.17 lbs
SNP8-3126 Details & Purchase	12” - 45”	37.7” - 141.3”	9’	(9) 2-3/8” x 126”	1,584.91 lbs

Magnum™ Full Walkway Snub-Nose Platform Kit

SKU	Pole Diameter	Pole Circumference	Face Width	Mounting Pipes	Weight
SNP12-NP Details & Purchase	12'' - 45''	37.7” - 141.3”	13’	N/A	1,733.18 lbs
SNP12-4126 Details & Purchase	12” - 45”	37.7” - 141.3”	13’	(12) 2-3/8” x 120”	2,147 lbs
SNP14-3126 Details & Purchase	12” - 45”	37.7” - 141.3”	15’	(9) 2-3/8” x 120”	2,033 lbs

RRU Ring Mount Kit

SKU	Size Range	Weight
UGLM-DCP Details & Purchase	10-1/2” - 28”	113 lbs

Tri-Sector T-Arm Kit for 6 Antennas (8" Standoff)

SKU	Pole Diameter	Face	Mounting Pipes	Weight
RDS-NP Details & Purchase	12” - 45”	5’ Pipe	None	530 lbs
RDS-296 Details & Purchase	12” - 45”	5’ Pipe	(6) 2-3/8” x 96”	705 lbs
RDS-2126 Details & Purchase	12” - 45”	5’ Pipe	(6) 2-3/8” x 120”	755 lbs
RDS-23084 Details & Purchase	12'' - 45''	5' Pipe	(6) 2-7/8'' x 84''	1,035 lbs

Compact Mount Kit

SKU	Pole Diameter	Weight
UWS6-NP Details & Purchase	10-1/2” - 28”	320 lbs

Mini T-Arm Kit

SKU	Pole Diameter	Face	Stand-Off Length	Weight
UDS-NP Details & Purchase	10-1/2” - 28”	5’ Pipe	18”	425 lbs
UDS-NPL Details & Purchase	10-1/2” - 28”	5’ Pipe	32”	465 lbs

Tri-Sector T-Arm Kit for 6 Antennas (36" Standoff)

SKU	Pole Diameter	Face	Mounting Pipes	Weight
RMV5-NP Details & Purchase	12'' - 45''	5' Pipe	None	685 lbs
RMV5-272 Details & Purchase	12'' - 45''	5' Pipe	(6) 2-3/8'' x 72''	995 lbs
RMV5-296 Details & Purchase	12” - 45”	5’ Pipe	(6) 2-3/8” x 96”	1,185 lbs
RMV5-2126 Details & Purchase	12” - 45”	5’ Pipe	(6) 2-3/8” x 120”	995 lbs
RMV5-3096 Details & Purchase	12” - 45”	5’ Pipe	(6) 2-7/8” x 96”	1,310 lbs
RMV5-SQNP Details & Purchase	12'' - 45''	5' Square Tube	None	755 lbs

Tri-Sector T-Arm Kit

SKU	Pole Diameter	Face	Mounting Pipes	Weight
RMV12-NP Details & Purchase	12'' - 45''	12' - 6'' Pipe	None	850 lbs
RMV12-472 Details & Purchase	12'' - 45''	13' Pipe	(12) 2-3/8'' x 72''	1,254 lbs
RMV12-484 Details & Purchase	12'' - 45''	13' Pipe	(12) 2-3/8'' x 84''	1,296 lbs
RMV12-396 Details & Purchase	12” - 45”	12’-6” Pipe	(9) 2-3/8” x 96”	1,285 lbs
RMV12-496 Details & Purchase	12” - 45”	12’-6” Pipe	(12) 2-3/8” x 96”	1,339 lbs
RMV12-4126 Details & Purchase	12” - 45”	13' Pipe	(12) 2-3/8” x 120”	1,339 lbs
RMV12-3126 Details & Purchase	12” - 45”	13' Pipe	(9) 2-3/8” x 120”	1,285 lbs
RMV12-SQNP Details & Purchase	12'' - 45''	12' - 6'' Square Tube	None	1,030 lbs

Ultra-Low-Profile Dual Level Rigid T-Arm Kit for 12 Antennas

SKU	Pole Diameter	Face Width	Mounting Pipes	Weight
ULPD12-496 Details & Purchase	12” - 45”	13'	(12) 2-3/8” x 96”	2 lbs
ULPD12-4126 Details & Purchase	12” - 45”	13'	(12) 2-3/8” x 120”	2 lbs

Monopole Dual-Level Tri-Sector T-Arm Kit

SKU	Pole Diameter	Standoff Length	Mounting Pipes	Face	Weight
RMVD8-296-18 Details & Purchase	12" - 45"	18"	(9) 2-3/8" x 96"	9'	1,881 lbs
RMVD8-2120-18 Details & Purchase	12" - 45"	18"	(9) 2-3/8" x 120"	9'	1,937 lbs
RMVD8-3-2120 Details & Purchase	12" - 45"	36"	(9) 2-3/8" x 120"	9'	2,255 lbs
RMVD10-4-296 Details & Purchase	12" - 45"	36"	(12) 2-3/8" x 96"	11'	2,355 lbs

Chain Mount Kit

SKU	Description	Range	Weight
CHM1 Details & Purchase	Single Sector	5” - 36”	60 lbs
CHM2 Details & Purchase	Double Sector	5” - 36”	100 lbs
CHM3 Details & Purchase	Triple Sector	6-1/2” - 36”	147 lbs

Taper-Adjustable Chain Mount Kit

SKU	Description	Standoff	Range	Weight
TCHM3 Details & Purchase	Triple Sector	1’	6-1/2” - 36”	195 lbs

Chain Mount Kit for Dish Antennas

SKU	Description	Weight
DCH8 Details & Purchase	HD Chain Mount with Stiff Arm	129.18 lbs

Monopole Mount Kit

SKU	Pole Diameter	Description	Weight
6CHMT Details & Purchase	17-1/2” - 56”	Six Sector	271 lbs

1/4” Galvanized Chain

SKU	Description	Weight
GC4-PF Details & Purchase	1/4” Galvanized Chain/ft	1 lb

V-Style Reinforcement Kits (Angle)

SKU	Description	Angle Size	Weight
PQ-SFS Details & Purchase	Quad Handrail Reinforcement Kit	L 2-1/2” x 2-1/2” x 1/4” x 120”	803 lbs

Lightweight T-Arm Kit

SKU	Pole Dia.	Weight
MP-LSM Details & Purchase	10-1/2” - 28”	270 lbs

Fortress™ Quad-Platform Mounts

SKU	Pole Diameter	Pole Circumference	Face Width	Weight
F4P-10W Details & Purchase	12” - 54”	37.7” - 169.6”	10’ - 6”	2,522 lbs

Universal Platform Support Rail Kit

SKU	Face Width	Support Rail Pipe Size	Antenna Mounting Pipe Size	Weight
HRK12 Details & Purchase	13'	2-3/8”	2-3/8”	227.55 lbs
HRK14 Details & Purchase	15'	2-3/8”	2-3/8”	267.9 lbs
HRK12-3HD Details & Purchase	13'	2-7/8”	2-3/8” or 2-7/8”	503 lbs
HRK14-3HD Details & Purchase	15'	2-7/8”	2-3/8” or 2-7/8”	525 lbs

Horizontal Support Rail Kit for Fortress™ Tri-Platform Mounts

SKU	Face Width	Support Rail Pipe Size	Antenna Mounting Pipe Size	Weight
F3P-HRK8 Details & Purchase	9'	2-3/8”	2-3/8” or 2-7/8”	374 lbs
F3P-HRK10 Details & Purchase	11'	2-3/8”	2-3/8” or 2-7/8”	391 lbs
F3P-HRK12 Details & Purchase	13'	2-3/8”	2-3/8” or 2-7/8”	405 lbs
F3P-HRK14 Details & Purchase	15'	2-3/8”	2-3/8” or 2-7/8”	415 lbs

Horizontal Support Rail Kit for Fortress™ Quad-Platform Mounts

SKU	Face Width	Support Rail Pipe Size	Antenna Mounting Pipe Size	Weight
F4P-HRK8 Details & Purchase	9'	2-3/8”	2-3/8” or 2-7/8”	464 lbs
F4P-HRK10 Details & Purchase	11'	2-3/8”	2-3/8” or 2-7/8”	480 lbs
F4P-HRK12 Details & Purchase	13'	2-3/8”	2-3/8” or 2-7/8”	507 lbs
F4P-HRK14 Details & Purchase	15'	2-3/8”	2-3/8” or 2-7/8”	550 lbs

Horizontal Support Rail Kit for Low-Profile Co-Location Platform

SKU	Description	Pipes	Weight
HRK12-U Details & Purchase	Support Rail Kit for 13' Face	2-3/8” and 2-7/8” Antenna Pipes	303 lbs
HRK14-U Details & Purchase	Support Rail Kit for 15' Face	2-3/8” and 2-7/8” Antenna Pipes	333 lbs

Support Rail Kit for Magnum™ Snub-Nose Platform

SKU	Compatible Plartform	Weight
HRA8 Details & Purchase	SNP8	310 lbs
HRA12 Details & Purchase	SNP12	415 lbs
HRA14 Details & Purchase	SNP14	440 lbs

Horizontal Support Rail

SKU	Weight
AHCP Details & Purchase	67 lbs

Horizontal Support Rail Reinforcement Kit

SKU	Angle Size	Weight
HSRK-35 Details & Purchase	L 3” x 3” x 1/4" x 96"	141.05 lbs

Reinforcement Kit for Platforms or T-Arms

SKU	Description	Pole Diameter	Horizontal Connection	Angle Size	Weight
PRK-1245 Details & Purchase	Reinforcement Kit	12" to 45"	4” x 4” Max	2L 2-1/2” x 2-1/2” x 3/16” x 52”	465 lbs
PRK-1245L Details & Purchase	Long Reinforcement Kit	12" to 45"	4” x 4” Max	2L 2-1/2” x 2-1/2” x 3/16” x 84”	520 lbs
PRK-NA Details & Purchase	Attachment Hardware Only	12" to 45"	4” x 4” Max	Order Separately	379 lbs
PRK-1245LW Details & Purchase	Reinforcement Kit, Wide Connection	12" to 45"	6” x 6” Max	2L 2-1/2” x 2-1/2” x 3/16” x 84”	564.12 lbs
PRK-HD Details & Purchase	Reinforcement Kit, Heavy-Duty Angle	12" to 45"	5” x 5” Max	2L 3” x 3” x 1/4” x 84"	610 lbs

Quad Reinforcement Kit for Platforms or T-Arms

SKU	Description	Pole Diameter	Horizontal Connection	Angle Size	Weight
PQ-1245 Details & Purchase	Reinforcement Kit	12" to 60"	4” x 4” Max	2L 2-1/2” x 2-1/2” x 3/16” x 52"	665 lbs
PQ-1245L Details & Purchase	Long Reinforcement Kit	12" to 60"	4” x 4” Max	2L 2-1/2” x 2-1/2” x 3/16” x 84"	735 lbs

V-Style Reinforcement Kit (Pipe)

SKU	Description	Pole Diameter	Horizontal Connection	Pipe Size	Weight
VSK-MHD Details & Purchase	Reinforcement Kit	12" to 45"	2-3/8” or 2-7/8”	2-7/8”	525 lbs
VSK-MHD-L Details & Purchase	Long Reinforcement Kit	12" to 45"	2-3/8” or 2-7/8”	2-7/8”	585 lbs

V-Style Reinforcement Kit (Angle)

SKU	Description	Angle Size	Weight
PRK-SFS Details & Purchase	Support Rail Reinforcement Kit	L 2-1/2” x 2-1/2” x 3/16” x 52-1/2”	588 lbs
PRK-SFS-L Details & Purchase	Long Angle Support Rail Reinforcement Kit	L 2-1/2” x 2-1/2” x 3/16” x 72”	642 lbs

Cable Platform Reinforcement Kit

SKU	Platform Style	Pole Diameter	Horizontal Connection	Weight
CRK-DC4 Details & Purchase	Fortress™ F4P	12” – 60”	4” x 4” Max	409 lbs

FLX Series™ Ring Mounts

SKU	Sectors	Pole Sizes	Weight
FLX3-HD Details & Purchase	3-Sided	12" - 44"	374.44 lbs
FLX4-HD Details & Purchase	4-Sided	12" - 60"	499.25 lbs

FLX Series™ Large Pole Adapter Kit

SKU	Pole Size	Weight
FLX-ADK Details & Purchase	45” - 60”	96 lbs

Universal Ring Mount Kit

SKU	Description	Pole Sizes	Weight
UQB4 Details & Purchase	Quad-Monopole Collar	12" - 60"	330 lbs
LWRM Details & Purchase	Tri-Monopole Collar	12" - 45"	250 lbs
RM-ADK Details & Purchase	Large Pole Adapter	45" - 60"	102 lbs

Lightweight Ring Mount Kit

SKU	Pole Sizes	Weight
UGLM Details & Purchase	10-1/2" - 28"	89 lbs
LP-42 Details & Purchase	28" - 42"	90 lbs
LP-6 Details & Purchase	6-5/8" - 10-1/2"	34 lbs
UGLM4 Details & Purchase	10-1/2" - 42"	111 lbs
QP-6 Details & Purchase	6-5/8" - 10-1/2"	46 lbs

Direct Frame Connection Kit

SKU	Description	Weight
MDFCC Details & Purchase	Monopole Direct Frame Connection Kit	634 lbs

Sector Frame Attachment Assembly

SKU	Description	Pole Sizes	Weight
MSFAA-Q Details & Purchase	Sector Frame Attachment Assembly (4 Sector)	12” - 60”	1,105 lbs
MSFAA Details & Purchase	Sector Frame Attachment Assembly (3 Sector)	12” - 45”	788.53 lbs
MSFAA-L Details & Purchase	Sector Frame Attachment Assembly Large (3 Sector)	45” - 60”	992 lbs

Monopole Sector Frame Attachment Assembly

SKU	Description	Pole Sizes	Weight
MSFAA-FLX3 Details & Purchase	Sector Frame Attachment Assembly (3 Sector) for FlexMax™ Collar	14” - 45”	937.29 lbs
MSFAA-FLX4 Details & Purchase	Sector Frame Attachment Assembly (4 Sector) for FlexMax™ Collar	15” - 60”	1,249.72 lbs

Support Arm Kit

SKU	Description	Weight
SV197-18 Details & Purchase	18” Support Arm	55 lbs
SV197-24 Details & Purchase	24” Support Arm	55 lbs
SV197-36 Details & Purchase	36” Support Arm	82 lbs
SV197-48 Details & Purchase	48” Support Arm	85 lbs

Standoff Arm Kit for Single Antennas

SKU	Description	Weight
MM01 Details & Purchase	8” Support Arm	37 lbs
MM02 Details & Purchase	24” Support Arm	51 lbs
MM03 Details & Purchase	36” Support Arm	62 lbs

Flush Mount Adapter Kit

SKU	Description	Pipe Size Range	Weight
FMA1 Details & Purchase	1 Plate and Hardware	1-1/2” - 4-1/2”	16 lbs
FMA1-2 Details & Purchase	2 Plates and Hardware	1-1/2” - 4-1/2”	30 lbs
FMA2 Details & Purchase	4 Plates and Hardware	1-1/2” - 4-1/2”	57 lbs

Cellular Pipe Frame

SKU	Length	Weight
SP216-12-NS Details & Purchase	13'	110 lbs
SP216-14-NS Details & Purchase	15'	126 lbs

Pipe Mount Kit

SKU	Mounting Pipe	Weight
SP219-72 Details & Purchase	(1) 2-3/8'' x 72''	43 lbs
SP219-96 Details & Purchase	2-3/8” x 96”	50 lbs
SP219-126 Details & Purchase	2-3/8” x 126”	60 lbs
SP219-96H Details & Purchase	2-7/8” x 96”	68 lbs
SP219-120H Details & Purchase	2-7/8” x 120”	86 lbs

Dual Standoff Arms

SKU	Pipe Sizes	Stand off	Weight
DSM2 Details & Purchase	2-3/8'', 2-7/8'' or 3-1/2''	28''	85.95 lbs

Rooftop Sites

Square Strut

SKU	Length	Slot Size	Spacing	Finish	Weight
UNT5 Details	60"	7/16" x 3"	4"	Electro Galvanized	8 lbs
UNT10 Details	120"	9/16" x 1-1/8"	2"	Electro Galvanized	18.5 lbs

Rubber Mats

SKU	Size	Weight
MAT18 Details	18" x 48"	15.5 lbs

Ballast Tie-Down Kit for Non-Penetrating Rooftop Mounts

SKU	Weight
CSRT-BTD Details & Purchase	12 lbs

Non-Penetrating Rooftop Angle Frames

SKU	Face Width	Mounting Pipes	Footprint	Mats Required	Weight
RTW-10-3-126 Details & Purchase	10’-6”	(3) 2-3/8” x 126”	93”W x 98”D	4	586 lbs
RTW-12-4-126 Details & Purchase	12’-6”	(4) 2-3/8” x 126”	93”W x 98”D	4	636 lbs

Non-Penetrating Rooftop Pipe Frames

SKU	Face Width	Mounting Pipes	Footprint	Mats Required	Weight
RTP10 Details & Purchase	10'-6''	No Pipes	92'' x 126''	6	535 lbs
RTP10-496 Details & Purchase	10’ - 6”	(4) 2-3/8” x 96”	92” x 126”	6	694 lbs
RTP10-4126 Details & Purchase	10’ - 6”	(4) 2-3/8” x 126”	92” x 126”	6	735 lbs
RTP12 Details & Purchase	12'-6''	No Pipes	92'' x 150''	8	667 lbs
RTP12-496 Details & Purchase	12’ - 6”	(4) 2-3/8” x 96”	92” x 150”	8	943 lbs
RTP12-4126 Details & Purchase	12’ - 6”	(4) 2-3/8” x 126”	92” x 150”	8	1,029 lbs
RTP14 Details & Purchase	14'-6''	No Pipes	92'' x 174''	12	800 lbs
RTP14-496 Details & Purchase	14’ - 6”	(4) 2-3/8” x 96”	92” x 174”	12	1,059.78 lbs
RTP14-4126 Details & Purchase	14’ - 6”	(4) 2-3/8” x 126”	92” x 174”	12	1,019.04 lbs

Non-Penetrating Rooftop Frames with RRU Mounts

SKU	Face Width	Mounting Pipes	Footprint	Mats Required	Weight
RTP10-3RRU Details & Purchase	10’-6”	(4) 2-3/8” x 174”	92” x 126”	6	1,049 lbs
RTP12-3RRU Details & Purchase	12’-6”	(4) 2-3/8” x 174”	92” x 150”	8	1,108 lbs
RTP14-3RRU Details & Purchase	14’-6”	(4) 2-3/8” x 174”	92” x 174”	12	1,375 lbs
RTP10-3RRU-NP Details & Purchase	10'-6''	No Pipes	92'' x 126''	6	830 lbs
RTP12-3RRU-NP Details & Purchase	12'-6''	No Pipes	92'' x 150''	8	930 lbs
RTP14-3RRU-NP Details & Purchase	14'-6''	No Pipes	92'' x 174''	12	1,155 lbs

Non-Penetrating Rooftop RRU Mounts

SKU	Face Width	Footprint	Mats Required	Weight
RT-RRU5HD Details & Purchase	5’	55” x 63”	2	282 lbs

Non-Penetrating Tripod

SKU	Description	Weight
TRPD-HD Details & Purchase	Non-Penetrating Tripod	400 lbs

Penetrating Rooftop Mounts

SKU	Description	Weight
TP1-12 Details & Purchase	12’ Single-Sector Penetrating Rooftop Mount	500 lbs

Cooper B-Line Dura-Blok™

SKU	Height	Width	Length	Weight
DB5 Details & Purchase	5”	6”	4.8”	3 lbs
DB10 Details & Purchase	5”	6”	9.6”	5.3 lbs
DB20 Details & Purchase	5”	6”	20.2”	11 lbs

Adjustable Splices for Rooftop Cable Kits

SKU	Application	Weight
SP1573 Details & Purchase	0-45° splice, 4-Run Kits	3.25 lbs
SP1574 Details & Purchase	0-45° splice, 8-Run Kits	10.5 lbs
SP1597 Details & Purchase	0-45° splice, 12-Run Kits	39.3 lbs

Rooftop Cable Run T-Stands

SKU	# of Runs	Height	Width	Use with Ladder	Weight
TL24-14 Details & Purchase	4	24”	14.5”	WCL4	60 lbs
TL24-20 Details & Purchase	6	24”	21”	WCL6	60 lbs
TL24-NP Details & Purchase	Custom	24”	Custom	Custom	40 lbs

Rooftop Cable Support Kits

SKU	# of Runs	Cover Size	Weight
SP1542 Details & Purchase	4	11-1/2” x 8’	100 lbs
SP1543 Details & Purchase	8	21-1/2” x 8’	91 lbs
SP1595 Details & Purchase	12	33” x 8’	200 lbs

Tall Rooftop Cable Support Kits

SKU	# of Holes for Snap-Ins	Cover Size	Weight
SP1542D Details & Purchase	4 (stack up to (8) 1-5/8” cables, or (12) 7/8” cables)	11-1/2” x 8’	85 lbs
SP1543D Details & Purchase	8 (stack up to (16) 1-5/8” cables, or (24) 7/8” cables)	21-1/2” x 8’	168 lbs
SP1595D Details & Purchase	12 (stack up to (24) 1-5/8” cables, or (36) 7/8” cables)	33” x 8’	264 lbs

Straight Aluminum Cable Tray

SKU	Width (W)	Length	Type	Pairs With	Rung Safe Load, Uniform	Weight
LT-06-4D Details & Purchase	6"	12'	Tray	LT-VSS-06-A	2,400 lbs	15 lbs
LT-VSS-06-A Details & Purchase	6"	12'	Cover	LT-06-4D	-	5 lbs
LT-09-4D Details & Purchase	9"	12'	Tray	LT-VSS-09-A	1,600 lbs	17 lbs
LT-VSS-09-A Details & Purchase	9"	12'	Cover	LT-09-4D	-	7 lbs
LT-12-4D Details & Purchase	12"	12'	Tray	LT-VSS-12-A	1,200 lbs	19 lbs
LT-VSS-12-A Details & Purchase	12"	12'	Cover	LT-12-4D	-	8 lbs
LT-18-4D Details & Purchase	18"	12'	Tray	LT-VSS-18-A	800 lbs	22 lbs
LT-VSS-18-A Details & Purchase	18"	12'	Cover	LT-18-4D	-	11 lbs
LT-24-4D Details & Purchase	24"	12'	Tray	LT-VSS-24-A	600 lbs.	23 lbs
LT-VSS-24-A Details & Purchase	24"	12'	Cover	LT-24-4D	-	15 lbs

45° Horizontal Bends

SKU	Width (W)	Type	Pairs With	Bend Radius (R)	Footprint (AxB)	Offset (CxD)	Weight
LT-C45-06-4D Details & Purchase	6”	Tray	LT-V45-06-A	12" at 45°	17-7/8" x 11-5/8"	31-1/2" x 13"	2 lbs
LT-V45-06-A Details & Purchase	6”	Cover	LT-C45-06-4D	-	-	-	1 lb
LT-C45-09-4D Details & Purchase	9”	Tray	LT-V45-09-A	12" at 45°	20" x 14-5/8"	33-5/8" x 13-7/8"	2.5 lbs
LT-V45-09-A Details & Purchase	9”	Cover	LT-C45-09-4D	-	-	-	1 lb
LT-C45-12-4D Details & Purchase	12”	Tray	LT-V45-12-A	12" at 45°	22-1/8" x 17-5/8"	35-3/4" x 14-3/4"	3 lbs
LT-V45-12-A Details & Purchase	12”	Cover	LT-C45-12-4D	-	-	-	1.25 lbs
LT-C45-18-4D Details & Purchase	18”	Tray	LT-V45-18-A	12" at 45°	26-3/8" x 23-5/8"	40" x 16-1/2"	4 lbs
LT-V45-18-A Details & Purchase	18”	Cover	LT-C45-18-4D	-	-	-	1.95 lbs
LT-C45-24-4D Details & Purchase	24”	Tray	LT-V45-24-A	12" at 45°	30-5/8" x 29-5/8"	44-1/8" x 18-1/4"	5 lbs
LT-V45-24-A Details & Purchase	24"	Cover	LT-C45-24-4D	-	-	-	2.75 lbs

90° Horizontal Bends

SKU	Width (W)	Type	Pairs With	Bend Radius (R)	Footprint (AxB)	Offset (CxD)	Weight
LT-C90-06-4D Details & Purchase	6”	Tray	LT-V90-06-A	12" at 90°	21" x 21"	36" x 36"	4 lbs
LT-V90-06-A Details & Purchase	6”	Cover	LT-C90-06-4D	-	-	-	1.5 lbs
LT-C90-09-4D Details & Purchase	9”	Tray	LT-V90-09-A	12" at 90°	24" x 24"	39" x 39"	5 lbs
LT-V90-09-A Details & Purchase	9”	Cover	LT-C90-09-4D	-	-	-	2 lbs
LT-C90-12-4D Details & Purchase	12”	Tray	LT-V90-12-A	12" at 90°	27" x 27"	42" x 42"	6 lbs
LT-V90-12-A Details & Purchase	12”	Cover	LT-C90-12-4D	-	-	-	2.6 lbs
LT-C90-18-4D Details & Purchase	18”	Tray	LT-C90-18-4D	12" at 90°	33" x 33"	48" x 48"	7 lbs
LT-V90-18-A Details & Purchase	18”	Cover	LT-C90-18-4D	-	-	-	3.95 lbs
LT-C90-24-4D Details & Purchase	24”	Tray	LT-V90-24-A	12" at 90°	39" x 39"	54" x 54"	8.35 lbs
LT-V90-24-A Details & Purchase	24”	Cover	LT-C90-24-4D	-	-	-	5.75 lbs

Horizontal T-Junctions

SKU	Size	Type	Pairs With	Bend Radius	End Widths (W1xW2)	Weight
LT-TJ-06-4D Details & Purchase	6”	Tray	LT-VTJ-06-A	12"	36" x 21"	8 lbs
LT-VTJ-06-A Details & Purchase	6”	Cover	LT-TJ-06-4D	-	-	6 lbs
LT-TJ-09-4D Details & Purchase	9”	Tray	LT-VTJ-09-A	12"	39" x 24"	9 lbs
LT-VTJ-09-A Details & Purchase	9”	Cover	LT-TJ-09-4D	-	-	6.5 lbs
LT-TJ-12-4D Details & Purchase	12”	Tray	LT-VTJ-12-A	12"	42" x 27"	10 lbs
LT-VTJ-12-A Details & Purchase	12”	Cover	LT-TJ-12-4D	-	-	7 lbs
LT-TJ-18-4D Details & Purchase	18”	Tray	LT-VTJ-18-A	12"	48" x 33"	11.35 lbs
LT-VTJ-18-A Details & Purchase	18”	Cover	LT-TJ-18-4D	-	-	7.6 lbs
LT-TJ-24-4D Details & Purchase	24”	Tray	LT-VTJ-24-A	12"	54" x 39"	13 lbs
LT-VTJ-24-A Details & Purchase	24”	Cover	LT-TJ-24-4D	-	-	8 lbs

Inside 90° Vertical Risers

SKU	Size	Type	Pairs With	Bend Radius	Dimensions	Weight
LT-RI90-06-4D Details & Purchase	6”	Tray	LT-VRI90-06-A	12" at 90°	21-1/4" x 21-1/4"	4.5 lbs
LT-VRI90-06-A Details & Purchase	6”	Cover	LT-RI90-06-4D	-	-	1.5 lbs
LT-RI90-09-4D Details & Purchase	9”	Tray	LT-VRI90-09-A	12" at 90°	21-1/4" x 21-1/4"	5 lbs
LT-VRI90-09-A Details & Purchase	9”	Cover	LT-RI90-09-4D	-	-	1.75 lbs
LT-RI90-12-4D Details & Purchase	12”	Tray	LT-VRI90-12-A	12" at 90°	21-1/4" x 21-1/4"	6 lbs
LT-VRI90-12-A Details & Purchase	12”	Cover	LT-RI90-12-4D	-	-	2.04 lbs
LT-RI90-18-4D Details & Purchase	18”	Tray	LT-VRI90-18-A	12" at 90°	21-1/4" x 21-1/4"	7 lbs
LT-VRI90-18-A Details & Purchase	18”	Cover	LT-RI90-18-4D	-	-	3 lbs
LT-RI90-24-4D Details & Purchase	24”	Tray	LT-VRI90-24-A	12" at 90°	21-1/4" x 21-1/4"	8 lbs
LT-VRI90-24-A Details & Purchase	24”	Cover	LT-RI90-24-4D	-	-	3.75 lbs

Outside 90° Vertical Risers

SKU	Width (W)	Type	Pairs With	Bend Radius	Dimensions	Weight
LT-RO90-06-4D Details & Purchase	6”	Tray	LT-VRO90-06-A	12" at 90°	15" x 15"	4.5 lbs
LT-VRO90-06-A Details & Purchase	6”	Cover	LT-RO90-06-4D	-	-	1.5 lbs
LT-RO90-09-4D Details & Purchase	9''	Tray	LT-VRO90-09-A	12" at 90°	15" x 15"	5 lbs
LT-VRO90-09-A Details & Purchase	9”	Cover	LT-RO90-09-4D	-	-	1.75 lbs
LT-RO90-12-4D Details & Purchase	12”	Tray	LT-VRO90-12-A	12" at 90°	15" x 15"	6 lbs
LT-VRO90-12-A Details & Purchase	12”	Cover	LT-RO90-12-4D	-	-	2.5 lbs
LT-RO90-18-4D Details & Purchase	18”	Tray	LT-VRO90-18-A	12" at 90°	15" x 15"	7 lbs
LT-VRO90-18-A Details & Purchase	18”	Cover	LT-RO90-18-4D	-	-	3.45 lbs
LT-RO90-24-4D Details & Purchase	24”	Tray	LT-VRO90-24-A	12" at 90°	15" x 15"	7 lbs
LT-VRO90-24-A Details & Purchase	24”	Cover	LT-RO90-24-4D	-	-	4.6 lbs

Straight Reducers

SKU	End Widths (W1xW2)	Type	Pairs With	Side Offset	Weight
248-12ST-06 Details & Purchase	12" to 6"	Tray	FS28-12ST-06	3"	1.2 lbs
FS28-12ST-06 Details & Purchase	12” to 6”	Cover	248-12ST-06	-	0.5 lbs
248-18ST-12 Details & Purchase	18” to 12”	Tray	FS28-18ST-12	3"	1.8 lbs
FS28-18ST-12 Details & Purchase	18” to 12”	Cover	248-18ST-12	-	0.8 lbs

Channel Type Cover Connectors

SKU	Size	Weight
248-06-DC Details & Purchase	6”	1.2 lbs
248-12-DC Details & Purchase	12”	1.6 lbs
248-24-DC Details & Purchase	24”	2 lbs

Ladder Hold-Down Clamp

SKU	Description	Material	Weight
9131 Details & Purchase	Hold-Down Clamp	Hot-Dip Galvanized Steel	0.1 lbs

Ladder Splice Plates

SKU	Description	Weight
LT-SS-A Details & Purchase	Pair of Straight Splices	1.8 lbs

Aluminum Step-Over Kits

SKU	A	B	C	D	Width	Foot Plates	Weight
UB10-24 Details & Purchase	10”	24”	13”	42.5”	36”	6” x 18”	55 lbs
UB10-36 Details & Purchase	10”	36”	13”	48”	18”	6” x 18”	65 lbs

Steel Step-Over Kits

SKU	Description	Weight
STEP48 Details & Purchase	Galvanized Steel Step-Over Kit	175 lbs

Wall Mounts & Chimney Mounts

Cantilever Wall Mounts

SKU	Description	Standoff	Weight
SP250 Details & Purchase	Two Cantilever Wall Mounts w/U-Bolts	2-3/4”	13.38 lbs

Angle Wall Mount Kits

SKU	Pipe OD	Angle Size	Mounting Holes	Standoff	Weight
WMA238 Details & Purchase	2-3/8”	3” x 3” x 15”	11/16” on 12” centers	3"	23.72 lbs
WMA300 Details & Purchase	2-7/8”	3” x 3” x 15”	11/16” on 12” centers	3"	23.82 lbs
WMA312 Details & Purchase	3-1/2”	4” x 4” x 24”	11/16” on 21” centers	4"	57 lbs
WMA412 Details & Purchase	4-1/2”	4” x 4” x 24”	11/16” on 21” centers	4"	57 lbs

Slider Bracket Wall Mount Kits

SKU	Description	Pipe OD	Weight
SBWM Details & Purchase	Two Slider Brackets w/ Hardware	2-3/8” - 2-7/8”	50.75 lbs

Standoff Wireless Wall Mounts

SKU	Stand Off	Weight
WWM02 Details & Purchase	2’	38 lbs
WWM03 Details & Purchase	3’	50 lbs

Heavy-Duty Wall Mount Brackets

SKU	Description	Qty.	Weight
SP221-12 Details & Purchase	12” Hollow Wall Kit	Kit of 2	80 lbs

Universal Adjustable Wall Mount Brackets

SKU	Standoff	Description	Weight
WMU-24S Details & Purchase	14” - 24”	Adjustable Wall Mount Bracket	26 lbs

Solid Wall Mount Kit

SKU	Weight
SWK58 Details & Purchase	9.2 lbs

Hollow Wall Mount Kit

SKU	Includes	Weight
HWK58 Details & Purchase	Four, 5/8" x 12" galvanized threaded rods	8.05 lbs

Ice Bridges & Equipment Racks

24″ Grip-Strut Ice Bridge Kits With Triple-Tee Trapeze

SKU	Size	Poles	Trapeze	# of Runs	Weight
IB24D-T3 Details & Purchase	24” x 10’, 12 Gauge	3-1/2” x 13’-4” Burial	Triple Tee	24	443 lbs
IB24D-216T3 Details & Purchase	24” x 10’, 12 Gauge	3-1/2” x 18’ Burial	Triple Tee	24	515 lbs
IB24B-T3 Details & Purchase	24” x 10’, 12 Gauge	3-1/2” x 10’-6” Base Shoe	Triple Tee	24	429 lbs
IB24D-T3-LW Details & Purchase	24” x 10’, 14 Gauge	3-1/2” x 13’-4”, Burial	Triple Tee	24	340 lbs

24″ Grip-Strut Ice Bridge Kits With Vertical T-Bracket Trapeze

SKU	Size	Poles	Trapeze	# of Runs	Weight
IB24D-V Details & Purchase	24” x 10’	3-1/2” x 13’-4” Burial	VT-Brackets	18	421 lbs
IB24B-V Details & Purchase	24” x 10’	3-1/2” x 10’-6” Base Shoe	VT-Brackets	18	407 lbs

24″ Grip-Strut Ice Bridge Kits With Z-Bracket Trapeze

SKU	Size	Poles	Trapeze	# of Runs	Weight
IB24D-Z Details & Purchase	24” x 10’	3-1/2” x 13’-4” Burial	Z-Brackets, 1 Level	14	423 lbs

24” Grip-Strut Ice Bridge Kits With Angle-Bracket Trapeze

SKU	Size	Poles	Trapeze	# of Runs	Weight
IB24D-A Details & Purchase	24'' x 10'	3-1/2'' x 13'-4'' Burial	Angle Brackets, 1 Level	6	415 lbs
IB24D-A2 Details & Purchase	24'' x 10'	3-1/2'' x 13'-4'' Burial	Angle Brackets, 2 Level	12	425 lbs

12″ Grip-Strut Ice Bridge Kits With Triple-Tee Trapeze

SKU	Size	Poles	Trapeze	# of Runs	Weight
IB12D-T3 Details & Purchase	12” x 10’	3-1/2” x 13’-4” Burial	T-Bracket, 3 Level	12	411 lbs
IB12B-T3 Details & Purchase	12” x 10’	3-1/2” x 10’-6” Base Shoe	T-Brackets, 3 Level	12	280 lbs

12″ Grip-Strut Ice Bridge Kits With Vertical T-Bracket Trapeze

SKU	Size	Poles	Trapeze	# of Runs	Weight
IB12B-V Details & Purchase	12” x 12’	3-1/2” x 10’-6” Base Shoe	VT-Brackets	18	362 lbs

12″ Grip-Strut Ice Bridge Kits With Z-Bracket Trapeze

SKU	Size	Poles	Trapeze	# of Runs	Weight
IB12D-Z2 Details & Purchase	12” x 12’	3-1/2” x 13’-4” Burial	Z-Brackets, 2 Level	14	397 lbs

Pipe Columns

SKU	Type	Size	Weight
SP126 Details & Purchase	Base Shoe	3-1/2” x 10’-6”	95 lbs
P3160 Details & Purchase	Direct Burial	3-1/2” x 13’-4”	101 lbs
P3252 Details & Purchase	Direct Burial	3-1/2” x 21’	160 lbs

Bolt-On Base Shoe

SKU	Description	Weight
BSA300 Details & Purchase	Bolt-On Base Shoe	12.5 lbs
GWA585 Details & Purchase	5/8” x 5” Galvanized Wedge Anchors (3 req’d)	2.3 lbs

Base Shoe Foot

SKU	Description	Weight
BSF35 Details & Purchase	Base Shoe Foot for 3-1/2” OD Pipe	14.15 lbs

Universal Cantilever Kit

SKU	Channel Width	Description	Weight
HHD12-K Details & Purchase	12”	Complete Cantilever Kit	11.25 lbs
HHD24-K Details & Purchase	24”	Complete Cantilever Kit	16.65 lbs

Grip-Strut Bridge Channel

SKU	Size	Gauge	Depth	Weight
GRS12 Details & Purchase	11-3/4” x 12’	12	2”	72 lbs
GRS24 Details & Purchase	24” x 10’	12	3”	104 lbs
LDGS10 Details & Purchase	24” x 10’	14	2”	73 lbs

Triple-Tee Trapeze Kit

SKU	# of Runs	Size	Weight
T24K-3 Details & Purchase	24	22” x 24-1/2”	17.15 lbs

Universal Z-Bracket Trapeze Kit

SKU	Description	Width	Threaded Rod	# of Runs	Weight
Z12K Details & Purchase	Single Stack, 1 Level	12”	3/8” x 18”	7	5.02 lbs

Equipment Rack

SKU	Pipes	Weight
ER105D Details & Purchase	3-1/2” x 13’ 4” Direct Burial Pipes	420 lbs
ER106B Details & Purchase	3-1/2” x 10’ Base Shoe Pipes	400 lbs

H-Frame Equipment Rack

SKU	Description	Weight
HF-556 Details & Purchase	H-Frame Equipment Rack	117 lbs

Platform Canopies

SKU	Size	Pipes	Weight
COV610 Details & Purchase	10’ x 6’	3-1/2” OD, 13’-4” Burial	1,000 lbs
COV810 Details & Purchase	10’ x 8’	3-1/2” OD, 13’-4” Burial	1,120 lbs
COV1010 Details & Purchase	10’ x 10’	3-1/2” OD, 13’-4” Burial	1,200 lbs
COV1012 Details & Purchase	10’ x 12’	3-1/2” OD, 13’-4” Burial	1,350 lbs
COV612 Details & Purchase	12' x 6'	3-1/2'' OD, 13' - 4'' Burial	1,100 lbs
COV812 Details & Purchase	12' x 8'	3-1/2'' OD, 13' - 4'' Burial	1,225 lbs
COV610-B Details & Purchase	10’ x 6’	3-1/2” OD, 10’-6” Base Shoe	970 lbs
COV810-B Details & Purchase	10’ x 8’	3-1/2” OD, 10’-6” Base Shoe	1,090 lbs
COV1010-B Details & Purchase	10’ x 10’	3-1/2” OD, 10’-6” Base Shoe	1,170 lbs
COV1012-B Details & Purchase	10’ x 12’	3-1/2” OD, 10’-6” Base Shoe	1,320 lbs
COV612-B Details & Purchase	12' x 6'	3-1/2'' OD, 10' - 6'' Base Shoe	1,070 lbs
COV812-B Details & Purchase	12' x 8'	3-1/2'' OD, 10' - 6'' Base Shoe	1,195 lbs

Equipment Platforms

8' x 8' MEP Platform

SKU	Size	Sub Assembly	Weight
MEP88-4S Details & Purchase	8' X 8'	MEP44, MPAD-S	950 lbs

10' x 10' MEP Platform

SKU	Size	Sub Assembly	Weight
MEP1010-7S Details	10' X 10'	MEP57 MEP53 MPAD-S	2,500 lbs

10' x 12' MEP Platform

SKU	Size	Sub Assembly	Weight
MEP1012-TMO4-K Details	10' X 12'	MEP46, MEP44, MPAD-L, MRAIL-6, MRAIL-4 MSTEP-SLIDE, MOPEN-4, MSPLICE-S, MSPLICE-C	3,240 lbs
MEP1012-TMO3-K Details	10' X 12'	MEP46, MEP44, MPAD-L, MRAIL-6, MRAIL-4 MSTEP-SLIDE, MOPEN-4, MSPLICE-S, MSPLICE-C	3,610 lbs
MEP1012-6LH44R5 Details & Purchase	10' X 12'	MEP46, MEP44, MPAD-L, MRAIL-6, MRAIL-4, MRAMP, MOPEN-4, MSPLICE-S, MSPLICE-C	2,873 lbs

10' MEP Platform, Handrail, Slide Step, Canopy

SKU	Size	Sub Assembly	Weight
MEP1010-7SSSCH Details	10' x 10'	MEP57, MEP53, MPAD-S, MOPHR-K, MCHR-K, MSTEP-SLIDE, MPCOV1010	0 lbs
MEP1010-7SSSRC Details & Purchase	10' x 10'	MEP57, MEP53, MPAD-S, MOPHR-K, MCHR-K, MSTEP-SLIDE, MPCOV1010	2,995.33 lbs

Ground Solution #2

SKU	Size	Sub Assembly	Weight
MEP88-8SH32S1C Details & Purchase	8' x 8'	MEP48, MPAD-S, MRAIL-4, MRAIL-2, MSTEP-1LD, MOPEN-4, MPCOV810, MSPLICE-S, MSPLICE-C	2,420 lbs

Platform Base Sections

SKU	Size	Description	Weight
MEP42 Details & Purchase	4' x 2'	Modular Equipment Platform Base	116.16 lbs
MEP44 Details & Purchase	4' x 4'	Modular Equipment Platform Base	220.26 lbs
MEP46 Details & Purchase	4' x 6'	Modular Equipment Platform Base	314.82 lbs
MEP48 Details & Purchase	4' x 8'	Modular Equipment Platform Base	409.38 lbs
MEP53 Details	5' x 3'	Modular Equipment Platform Base	200 lbs
MEP57 Details	5' x 7'	Modular Equipment Platform Base	400 lbs

Platform Ice Bridge Kits

SKU	Description	Weight
MIBP-2410 Details & Purchase	24" x 10' Platform Ice Bridge Kit	375 lbs
MIBP-2412 Details & Purchase	24" x 12' Platform Ice Bridge Kit	385 lbs
MIBP-2410L Details & Purchase	24" x 10' x 10' L-Shaped Platform Ice Bridge Kit	595 lbs

Footpads & Extentions

SKU	Pad Size	Description	Deck Height Adjustment	Weight
MPAD-S Details & Purchase	12" x 12"	Small Footpad	13" - 18-1/2"	22.25 lbs
MPAD-L Details & Purchase	18" X 18"	Large Footpad	13" - 18-1/2"	38.13 lbs
MPAD-BRC Details & Purchase	N/A	Footpad Extension Bracing Kit	N/A	6.2 lbs
MPAD-EX33 Details & Purchase	N/A	Footpad Extension	27-1/2" - 32-1/2"	30 lbs
MPAD-EX48 Details & Purchase	N/A	Footpad Extension	42-1/2" - 47-1/2"	60 lbs

Leveling Kit for Sloped Surfaces

SKU	Description	Weight
MLEVEL Details & Purchase	Footpad Leveling Kit	0.62 lbs

Standard and Extended Jacks

SKU	Pad Size	Description	Deck Height Adjustment	Weight
MJACK Details & Purchase	12" x 12"	5,000 lb Side Crank Jack w/ Small Footpad	13" - 28"	35.46 lbs
MJACK-EXT Details & Purchase	18" X 18"	5,000 lb Side Crank Jack Extended w/ Large Footpad	28" - 43"	70.7 lbs

Access Point/Finishing Kit

SKU	Description	Weight
MOPEN-4 Details & Purchase	Access Point/Finishing Kit	122.68 lbs

Handrail Kits

SKU	Size	Description	Weight
MRAIL-2 Details & Purchase	2' x 42"	2' Handrail Kit	30 lbs
MRAIL-4 Details & Purchase	4' x 42"	4' Handrail Kit	64.44 lbs
MRAIL-6 Details & Purchase	6' x 42"	6' Handrail Kit	103.92 lbs

Step and Access Kits with Handrails

SKU	Width	Platform Deck Height	Description	Weight
MSTEP-1 Details & Purchase	35-1/2"	9" - 14"	Fixed Height Stair Kit	54.47 lbs
MSTEP-2 Details & Purchase	32"	14" - 23"	Two-Step Adjustable Stair Kit	159.38 lbs
MSTEP-3 Details & Purchase	32"	19" - 34"	Three-Step Adjustable Stair Kit	215.77 lbs
MSTEP-4 Details & Purchase	32"	24" - 43"	Four-Step Adjustable Stair Kit	273.01 lbs

Step Kits without Handrails

SKU	Width	Platform Deck Height	Description	Weight
MSTEP-1LD Details & Purchase	35-1/2"	9" - 14"	One-Step Direct Connect Stair Kit	82 lbs
MSTEP-2LD Details & Purchase	35-1/2"	14" - 23"	Two-Step Direct Connect Stair Kit	143 lbs

Bolt-On Sliding Step

SKU	Width	Platform Deck Height	Description	Weight
MSTEP-SLIDE8 Details & Purchase	35-1/2"	9" - 14"	One-Step Slidable Direct Connect Stair Kit (8" Channel)	95 lbs

Ramp Kit

SKU	Width	Platform Deck Height	Description	Weight
MRAMP-5 Details & Purchase	35-1/2"	4" - 26"	Adjustable Ramp Kit	163.24 lbs
MCHAIN Details & Purchase	---	---	Chain Guard	5.2 lbs

Ladder Kits

SKU	Width	Description	Weight
MLADDER1 Details & Purchase	16"	1 Rung Ladder Kit	45 lbs
MLADDER3 Details & Purchase	16"	3 Rung Ladder Kit	64 lbs
MLADDER5 Details & Purchase	16”	5 Rung Ladder Kit	78 lbs
MBRAIL Details & Purchase	N/A	Backing Rail Kit	42 lbs

Rubber Mats

SKU	Size	Weight
MMAT Details & Purchase	1/2" x 18" x 18"	5.8 lbs

Square Strut

SKU	Description	Weight
UNT5-HFK Details & Purchase	5' Strut has 7/16" x 3" slots with 4" spacing	16 lbs
UNT10-HFK Details & Purchase	10' Strut has 7/16" x 3" slots with 4" spacing	21.41 lbs

Platform Cover Kits

SKU	Description	Weight
MPCOV1012 Details & Purchase	10' x 12' Equipment Platform Cover Kit	1,140 lbs
MPCOV1010-R Details	10' x 10' Equipment Platform Cover Kit	1,165 lbs
MPCOV610 Details & Purchase	6' x 10' Equipment Platform Cover Kit	895 lbs
MPCOV810 Details & Purchase	8' x 10' Equipment Platform Cover Kit	930 lbs
MPCOV812 Details & Purchase	8' x 12' Equipment Platform Cover Kit	1,019 lbs
MPCOV1010 Details & Purchase	10' x 10' Equipment Platform Cover Kit	1,019 lbs
MBRACE Details	MPOST Brace Kit	28.03 lbs

Platform Equipment Rack Kits

SKU	Overall Size	Deck Length	Description	Weight
MER8-H Details & Purchase	8'	8'	H-Frame with handrail attachment kit	263.99 lbs
MER8-P Details & Purchase	8'	8'	H-Frame with direct platform attachment kit	207.79 lbs

Pipe Mount Kit

SKU	Pipe Size	Clamp Thickness	Threaded Rod	Kit Qty.	Weight
MPIPEM Details & Purchase	1-1/2" - 5"	1/2"	5/8" x 18"	Kit of 2	15 lbs

Splice Connection Kits

SKU	Description	Weight
MSPLICE-C Details & Purchase	Handrail Corner Connection Kit	7.58 lbs
MSPLICE-S Details & Purchase	Handrail Straight Connection Kit	6.55 lbs

Cable Support

PIM Shield® Round Member Trapezoid

SKU	Size	Qty.	Weight
PIMTRAP Details	3-7/16" x 2-1/8" x 1-5/8"	10	1 lb

PIM Shield® Snap-In Cable Support Bars

SKU	Type	Positions	Qty.	Weight
900352-01 Details & Purchase	Standard	13	1	6.5 lbs
900352-02 Details & Purchase	Extended Range	13	1	7 lbs
900353-01 Details & Purchase	Extended Range	22	1	8 lbs
900353-02 Details & Purchase	Extended Range	22	1	8.5 lbs
901166-02-3 Details & Purchase	Extended Range	26	3	29.5 lbs
901167-02-3 Details & Purchase	Extended Range	44	3	39 lbs
900354 Details & Purchase	Extra Bar Kit	13	1	3 lbs
900355 Details & Purchase	Extra Bar Kit	22	1	5 lbs

Universal T-Bracket

SKU	# of Snap-In Holes	Round Member Size	60° Angle Legs	90° Angle Legs	Weight
T600 Details & Purchase	6	1-1/2" - 6"	2-1/2" - 8"	2-1/2" - 5"	6 lbs

Super Universal Double T-Brackets

SKU	# of Snap-In Holes	Round Member Size	60° Angle Legs	90° Angle Legs	Weight
DBT1200 Details & Purchase	24	1-1/2" - 6"	2-1/2" - 8"	2-1/2" - 5"	12.5 lbs

Universal Round-Member Support Bracket

SKU	# of Snap-In Holes	# of 7/16" Holes	Weight
MS6 Details & Purchase	6	6	1 lb

PIM-Mitigating Multi-Run Cable Support Kit

SKU	# of Snap-In Holes	# of 7/16" Holes	Weight
RRU-UT12 Details & Purchase	12	12	8 lbs

Rubber End Caps

SKU	Strut Size	Color	Weight
UNICAP Details & Purchase	1-5/8"	White	0.05 lbs
REDCAP Details & Purchase	1-5/8"	Red	0.05 lbs

Hardware

Pipe-to-Pipe Clamp Sets

SKU	Pipe Size	Clamp Thickness	Threaded Rod	Kit Qty.	Weight
SP1-MSK3 Details	1-1/2" - 3-1/2"	1/2"	1/2" x 10"	Kit of 2	28 lbs
ACP10K Details & Purchase	1-1/2" - 3-1/2"	1/4"	1/2" x 10"	Kit of 2	8.15 lbs
SCP10K Details & Purchase	1-1/2" - 3-1/2"	1/2"	1/2" x 10"	Kit of 2	11.9 lbs
DCP12K Details & Purchase	1-1/2" - 5"	1/2"	5/8" x 12"	Kit of 2	21.34 lbs
DCP18K Details & Purchase	1-1/2" - 5"	1/2"	5/8" x 18"	Kit of 2	25.25 lbs

Welded Pipe-to-Pipe Clamp Sets

SKU	Pipe Size	Clamp Thickness	Threaded Rod	Kit Qty.	Weight
SCP10W Details & Purchase	1-1/2" - 3-1/2"	1/2"	1/2" x 10"	Kit of 2	11.32 lbs

Universal Pipe-to-Pipe Clamp Sets

SKU	Pipe Size	Angle Size	Threaded Rod	Threaded Rod	Kit Qty.	Weight
UPC1 Details & Purchase	1-1/4" - 4-1/2"	1-1/2" - 3"	1/2" x 10"	(4) 1/2" x 10"	Kit of 2	19.4 lbs
UPC2 Details & Purchase	1-1/4" - 4-1/2" 1-1/2" - 3"	1-1/4" - 10" 3" - 7"	1/2" x 10"	(8) 1/2" x 15"	Kit of 2	22 lbs

Three-Way Universal Pipe-to-Pipe Clamp Sets

SKU	Side Pipes Size	Center Pipe Size	Threaded Rod	Kit Qty.	Weight
3WPP-UPC Details & Purchase	1-1/4" - 4-1/2"	1-1/4" - 10"	1/2" x 15"	Kit of 2	32 lbs

Three-Way Pipe-to-Pipe Clamp Sets

SKU	Pipe Size	Clamp Thick Ness	Threaded Rod	Qty.	Weight
3WPP-DCP Details & Purchase	1-1/2'' - 5''	1/2''	5/8'' x 24''	Kit of 2	42 lbs

Universal Standoff Pipe-To-Pipe Kits

SKU	Standoff Distance	Round Member Size	Weight
SOPTP24-U Details & Purchase	24"	2.375'' - 4.5'' O.D.	53 lbs

Crossover Plates

SKU	Smaller Pipe Size	Larger Pipe Size	Size	Qty.	Weight
SCX1 Details & Purchase	2-3/8"	2-3/8"	3/8" x 6" x 6"	Each (No Hardware)	3.5 lbs
SCX2 Details & Purchase	2-3/8" - 2-7/8"	2-3/8" - 2-7/8"	3/8" x 7" x 7"	Each (No Hardware)	4.8 lbs
SCX3 Details & Purchase	3-1/2"	3-1/2"	3/8" x 8" x 9"	Each (No Hardware)	7.25 lbs
SCX4 Details & Purchase	2-3/8" - 2-7/8"	2-7/8" - 4-1/2"	3/8" x 7" x 8-1/2"	Each (No Hardware)	5.85 lbs
SCX6 Details & Purchase	2-3/8" - 2-7/8"	4-1/2" - 6-5/8"	1/2" x 7" x 11"	Each (No Hardware)	9.05 lbs
SCX7 Details & Purchase	3-1/2"	4-1/2"	3/8" x 7" x 8"	Each (No Hardware)	7.3 lbs

Crossover Plate Kits

SKU	Smaller Pipe Size	Larger Pipe Size	Thickness	Qty.	Weight
SCX1-K Details & Purchase	2-3/8"	2-3/8"	3/8"	1 Plate, 4 U-Bolts & Hardware	6.78 lbs
SP1-MSK1 Details	2-7/8"	2-7/8"	3/8"	1 Plate, 4 U-Bolts & Hardware	12.5 lbs
SCX2-K Details & Purchase	2-3/8"	2-7/8"	3/8"	1 Plate, 4 U-Bolts & Hardware	7.65 lbs
SCX23-K Details & Purchase	2-7/8"	2-7/8"	3/8"	1 Plate, 4 U-Bolts & Hardware	8 lbs
SCX3-K Details & Purchase	3-1/2"	3-1/2"	3/8"	1 Plate, 4 U-Bolts & Hardware	10.21 lbs
SCX43-K Details & Purchase	2-3/8"	3-1/2"	3/8"	1 Plate, 4 U-Bolts & Hardware	9.25 lbs
SCX4-K Details & Purchase	2-3/8"	4-1/2"	3/8"	1 Plate, 4 U-Bolts & Hardware	15.65 lbs
SCX45-K Details & Purchase	2-7/8"	3-1/2"	3/8"	1 Plate, 4 U-Bolts & Hardware	15.65 lbs
SCX6-K Details & Purchase	2-7/8"	4-1/2"	1/2"	1 Plate, 4 U-Bolts & Hardware	12.25 lbs
SCX7-K Details & Purchase	3-1/2"	4-1/2"	1/2"	1 Plate, 4 U-Bolts & Hardware	11.2 lbs
SCX34-K Details & Purchase	4-1/2"	4-1/2"	3/8"	1 Plate, 4 U-Bolts & Hardware	13 lbs

Universal Crossover Plate Kits

SKU	Smaller Pipe Size	Larger Pipe Size	Thickness (Hardware Size)	Qty.	Weight
SCX3-U Details & Purchase	1-1/2" - 4-1/2"	1-1/2" - 4-1/2"	3/8" (1/2")	1 Plate, 4 V-Clamps & Hardware	16 lbs
SCX6-U Details & Purchase	1-1/2" - 2-7/8"	2-1/2" - 6"	1/2" (1/2")	1 Plate, 4 V-Clamps & Hardware	16.75 lbs
SCX7-U Details & Purchase	1-1/2" - 3-1/2"	1-1/2" - 4-1/2"	1/2" (1/2")	1 Plate, 4 V-Clamps & Hardware	15.74 lbs

Crossover Plate Kits for Square Tube/Pipe

SKU	Pipe Size	Square Tube Size	Thickness	Quantity	Weight
STCX43-K Details & Purchase	2-3/8"	Up to 3"	3/8"	1 Plate, 2 U-Bolts, 2 Bolts & Backing Plates	12 lbs
STCX45-K Details & Purchase	2-7/8"	Up to 3"	3/8"	1 Plate, 2 U-Bolts, 2 Bolts & Backing Plates	12 lbs
SQCX4-K Details & Purchase	2-3/8" or 2-7/8"	4"	3/8"	1 Plate, 4 U-Bolts, 2 Square U-Bolts & Hardware	11.35 lbs

Pipe/Angle Crossover Plate Kits

SKU	Angle Size	Pipe Size	Thickness	Qty.	Weight
ACX238-K Details & Purchase	3" x 3"	2-3/8"	3/8"	1 Plate, 4 U-Bolts & Hardware	9.67 lbs
ACX278-K Details & Purchase	3" x 3"	2-7/8"	3/8"	1 Plate, 4 U-Bolts & Hardware	9.82 lbs

Pipe Cross Support Plates

SKU	Smaller Pipe Size	Larger Pipe Size	Contents	Weight
FCX45-U Details & Purchase	2-3/8" - 4-1/2"	2-3/8" - 4-1/2"	1 Plate, 4 V-Clamps & Hardware	25.62 lbs
SP219 Details & Purchase	2-3/8"	3-1/2"	1 Bracket, 4 U-Bolts	11.3 lbs
SP219-H Details & Purchase	2-7/8"	3-1/2"	1 Bracket, 4 U-Bolts	13 lbs
SP216 Details & Purchase	3-1/2"	4-1/2"	1 Bracket, 6 U-Bolts	30 lbs

Pipe/Square Tube Cross Support Plate

SKU	Smaller Pipe Size/Square Tube Size	Larger Pipe Size	Contents	Weight
SP216-CK Details & Purchase	1-1/2" to 3-1/2"	4-1/2"	1 Bracket, 1 Crossover Plate, 12 Bolts, 4 V-Clamps	45 lbs

Crossover Clamp Sets

SKU	Smaller Pipe Size	Larger Pipe Size	Weight
SSCK Details & Purchase	Ø1-1/2" - Ø3-1/2"	Ø1-1/2" - Ø3-1/2"	6.25 lbs
DSCK Details & Purchase	Ø1-1/2" - Ø3-1/2"	Ø2-3/8" - Ø5"	9.55 lbs

Back-to-Back Pipe Mount Kits

SKU	Pipe Sizes	Stand-Off Arms	Weight
BBPM-K2 Details & Purchase	2-7/8"	3-1/2" - 4-1/2"	18 lbs
BBPM-K3 Details & Purchase	2-3/8"	3-1/2" - 6"	20 lbs
BBPM-U Details & Purchase	2-3/8" - 4-1/2"	2-3/8" - 4-1/2"	25 lbs

Clamp Halves

SKU	Overall Size	Hardware Size	Hole Size	Hole Spacing (c-c)	Thickness	Weight
ACP Details & Purchase	5-3/4"	1/2"	9/16" x 3/4"	4-1/16"	1/4"	0.6 lbs
SCP Details & Purchase	5-3/4"	1/2"	9/16" x 3/4"	4-1/16"	1/2"	1.05 lbs
DCP Details & Purchase	8-1/8"	5/8"	11/16" x 1"	5-3/4"	1/2"	2 lbs
MCP Details & Purchase	11-5/8"	5/8"	11/16" x 1"	9-1/2"	1/2"	3 lbs

V-Clamp Halves

SKU	Overall Size	Hardware Size	Hole Size	Hole Spacing (c-c)	Thickness	Weight
X-116165 Details & Purchase	5"	1/2"	9/16" x 3/4"	3"	3/8"	0.75 lbs
X-100064 Details & Purchase	6"	1/2"	9/16" x 3/4"	4"	3/8"	0.95 lbs
X-115765 Details & Purchase	7"	1/2"	9/16" x 3/4"	5"	3/8"	1.05 lbs
X-104223 Details & Purchase	8-5/8"	1/2"	9/16" x 3/4"	6-5/8"	3/8"	1.4 lbs

Heavy-Duty Clip Angles

SKU	Hardware Size	Slot Size	Dimensions	Weight
CA38 Details & Purchase	3/8"	7/16" x 1-1/2"	3" x 3" x 2" x 1/4"	0.5 lbs

Universal Heavy Splice

SKU	Slot Size	Dimensions	Thickness	Weight
SPLICE Details & Purchase	7/16" vs 4/16"	1-1/2" x 7-3/8"	3-16"	0.6 lbs

Bulk Pipe (Schedule 40 & 80)

SKU	Outer Diameter (OD) (in)	Length (in)	Schedule	Weight
P3174 Details	3-1/2	180	40	110 lbs
P3150 Details	3-1/2	150	40	88 lbs
P3126 Details	3-1/2	126	40	80 lbs
P30174 Details	2-7/8	174	40	78 lbs
P30150 Details	2-7/8	150	40	75 lbs
P2174 Details	2-3/8	174	40	56 lbs
P2150 Details	2-3/8	150	40	42.4 lbs
P260 Details & Purchase	2-3/8	60	40	17.4 lbs
P263 Details & Purchase	2-3/8	63	40	18.25 lbs
P272 Details & Purchase	2-3/8	72	40	23 lbs
P284 Details & Purchase	2-3/8	84	40	26 lbs
P296 Details & Purchase	2-3/8	96	40	27.8 lbs
P2108 Details & Purchase	2-3/8	108	40	34 lbs
P2120 Details & Purchase	2-3/8	120	40	37 lbs
P2126 Details	2-3/8	126	40	38 lbs
P2252 Details & Purchase	2-3/8	252	40	77 lbs
P3072 Details & Purchase	2-7/8	72	40	35 lbs
P3084 Details & Purchase	2-7/8	84	40	41 lbs
P3096 Details & Purchase	2-7/8	96	40	49 lbs
P30108 Details & Purchase	2-7/8	108	40	55 lbs
P30120 Details & Purchase	2-7/8	120	40	60 lbs
P30126 Details & Purchase	2-7/8	126	40	64 lbs
P30252 Details & Purchase	2-7/8	252	40	122 lbs
P360 Details & Purchase	3-1/2	60	40	38 lbs
P372 Details & Purchase	3-1/2	72	40	47 lbs
P384 Details & Purchase	3-1/2	84	40	53.2 lbs
P396 Details & Purchase	3-1/2	96	40	65 lbs
P3108 Details & Purchase	3-1/2	108	40	66 lbs
P3120 Details & Purchase	3-1/2	120	40	80 lbs
P4126 Details & Purchase	4-1/2	126	40	106 lbs
P4252 Details & Purchase	4-1/2	252	40	249 lbs
P496 Details & Purchase	4-1/2	96	40	87 lbs
P2252-80 Details & Purchase	2-3/8	252	80	106 lbs
P30126-80 Details	2-7/8	126	80	85 lbs
P30252-80 Details & Purchase	2-7/8	252	80	170 lbs
P3252-80 Details & Purchase	3-1/2	252	80	217 lbs

Bulk Angle

SKU	Size	Grade	Weight
ANG214 Details & Purchase	2" x 2" x 1/4" x 20'	36 ksi	52 lbs
ANG314 Details & Purchase	3" x 3" x 1/4" x 20'	Dual-Certified (Meets 50 ksi)	102 lbs
ANG414 Details & Purchase	4" x 4" x 1/4" x 20'	Dual-Certified (Meets 50 ksi)	138 lbs

U-Bolts

SKU	Diameter (D)	Width (W)	Length (L)	Thread (T)	Qty.	Weight
UB5418 Details & Purchase	5/8"	4-1/8"	7"	3"	Each	1.5 lbs
UB3200 Details & Purchase	3/8"	2"	3"	1-1/4"	Each	0.4 lbs
UB3212 Details & Purchase	3/8"	2-1/2"	3-5/8"	1-3/4"	Each	0.45 lbs
UB3300 Details & Purchase	3/8"	3"	4-1/4"	2"	Each	0.5 lbs
UB3312 Details & Purchase	3/8"	3-1/2"	4-3/4"	2"	Each	0.5 lbs
UB3418 Details & Purchase	3/8"	4"	5-3/4"	2-1/2"	Each	0.6 lbs
UB1400 Details & Purchase	1/2"	2"	4"	2"	Each	0.65 lbs
UB1212 Details & Purchase	1/2"	2-1/2"	4-1/2"	2"	Each	0.65 lbs
UB1212-B Details & Purchase	1/2"	2-1/2"	4-1/2"	2"	100	68 lbs
UB1300 Details & Purchase	1/2"	3"	5"	2"	Each	0.7 lbs
UB1300-B Details & Purchase	1/2"	3"	5"	2"	50	42.7 lbs
UB1358 Details & Purchase	1/2"	3-5/8:	5-1/2"	3"	Each	0.75 lbs
UB1358-B Details & Purchase	1/2"	3-5/8:	5-1/2"	3"	50	41 lbs
UB1306 Details & Purchase	1/2"	3-5/8"	6"	3"	Each	0.8 lbs
UB1418 Details & Purchase	1/2"	4-1/8"	6"	3"	Each	0.9 lbs
UB1458 Details & Purchase	1/2"	4-5/8"	7"	3"	Each	0.9 lbs
UB5258 Details & Purchase	5/8"	2-5/8"	4-1/2"	2"	Each	1.2 lbs
UB5300 Details & Purchase	5/8"	3"	5-1/4"	2-1/2"	Each	1.45 lbs
UB5300-B Details & Purchase	5/8"	3"	5-1/4"	2-1/2"	25	40 lbs
UB5358 Details & Purchase	5/8"	3-5/8"	6"	3"	Each	1.45 lbs
UB5458 Details & Purchase	5/8"	4-5/8"	7"	3"	Each	1.6 lbs

Square U-Bolts

SKU	Diameter (D)	Width (W)	Length (L)	Thread (T)	Qty.	Weight
SUB1418 Details & Purchase	1/2"	4-1/8"	6"	3"	Each	0.92 lbs
SUB1418-B Details & Purchase	1/2"	4-1/8"	6"	3"	25	23 lbs

J-Bolts

SKU	Diameter x Width x Length x Thread	Weight
JB8 Details & Purchase	3/8" x 5/8" x 8" x 6"	0.3 lbs

Stainless Steel Threaded Rod Kits

SKU	Rod	Kit Components	Weight
CH35 Details & Purchase	3/8" x 3-1/2"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	1.75 lbs
CH50 Details & Purchase	3/8" x 5"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	2.1 lbs
CH65 Details & Purchase	3/8" x 6-1/2"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	2.45 lbs
CH80 Details & Purchase	3/8" x 8"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	2.85 lbs
CH95 Details & Purchase	3/8" x 9-1/2"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	3.2 lbs
CH120 Details & Purchase	3/8" x 12"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	3.8 lbs

Stainless Steel Threaded Rods

SKU	Diameter	Length	Type	Weight
SS38R-18 Details & Purchase	3/8"	18"	304 Stainless Steel	0.45 lbs
SS38R-30 Details & Purchase	3/8''	30''	304 SS	0.75 lbs
SS38R-36 Details & Purchase	3/8"	36"	304 Stainless Steel	0.9 lbs
SS38R-72 Details & Purchase	3/8"	72"	304 Stainless Steel	1.7 lbs
SS58R-72 Details & Purchase	5/8''	72''	304 SS	5.05 lbs

Galvanized Threaded Rod Kits

SKU	Rod	Kit Components	Weight
CH65-G Details & Purchase	3/8" x 6-1/2"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	2.45 lbs
CH80-G Details & Purchase	3/8" x 8"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	2.85 lbs
CH95-G Details & Purchase	3/8" x 9-1/2"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	3.2 lbs
CH120-G Details & Purchase	3/8" x 12"	10 Rods, 30 each Flat Washers, Lock Washers, and Nuts	3.8 lbs

Galvanized Threaded Rods

SKU	Diameter	Length	Type	Weight
G38R-72 Details & Purchase	3/8"	72"	Hot-Dip Galvanized	1.8 lbs
G12R-6 Details & Purchase	1/2"	6"	Hot-Dip Galvanized	0.25 lbs
G12R-8 Details & Purchase	1/2"	8"	Hot-Dip Galvanized	0.35 lbs
G12R-10 Details & Purchase	1/2"	10"	Hot-Dip Galvanized	0.45 lbs
G12R-12 Details & Purchase	1/2"	12"	Hot-Dip Galvanized	0.5 lbs
G12R-20 Details & Purchase	1/2"	20"	Hot-Dip Galvanized	0.9 lbs
G12R-24 Details & Purchase	1/2"	24"	Hot-Dip Galvanized	1.1 lbs
G12R-72 Details & Purchase	1/2"	72"	Hot-Dip Galvanized	3.2 lbs
G58R-12 Details & Purchase	5/8"	12"	Hot-Dip Galvanized	0.85 lbs
G58R-14 Details & Purchase	5/8"	14"	Hot-Dip Galvanized	1 lb
G58R-24 Details & Purchase	5/8"	24"	Hot-Dip Galvanized	1.7 lbs
G58R-48 Details & Purchase	5/8"	48"	Hot-Dip Galvanized	3.45 lbs

Threaded Rod End Caps

SKU	Description	Quantity	Weight
TRC38-B Details & Purchase	3/8'' Threaded Rod Cap	Packs of 100	1 lb
TRC38 Details & Purchase	3/8'' Threaded Rod Cap	Packs of 100	0.5 lbs
TRC12 Details & Purchase	1/2'' Threaded Rod Cap	Packs of 100	0.5 lbs
TRC58 Details & Purchase	5/8'' Threaded Rod Cap	Packs of 100	0.5 lbs

Ground Lug Washers

SKU	Stud Size	Hole Spacing	Qty.	Weight
GW381 Details & Purchase	3/8"	1"	Pack of 10	0.1 lbs
GW3U Details & Purchase	3/8"	3/4" - 1"	Pack of 10	0.1 lbs

Stainless Steel Hex Head Bolts

SKU	Size	Qty.	Weight
SS14114 Details & Purchase	1/4" x 1-1/4"	Pack of 100	2.1 lbs
SS38114 Details & Purchase	3/8" x 1-1/4"	Pack of 100	4.7 lbs
SS38112 Details & Purchase	3/8" x 1-1/2"	Pack of 100	5.5 lbs

Stainless Steel Hex Nuts

SKU	Size	Qty.	Weight
SS38NUT-100 Details & Purchase	3/8"	Pack of 100	1.6 lbs
SS38NUT Details & Purchase	3/8"	Pack of 500	7.7 lbs

Stainless Steel Lock Washers

SKU	Size	Qty.	Weight
SS38LW-100 Details & Purchase	3/8"	Pack of 100	0.6 lbs
SS38LW Details & Purchase	3/8"	Pack of 500	3.1 lbs

Stainless Steel Flat Washers

SKU	Size	OD	Qty.	Weight
SS14FW-100 Details & Purchase	1/4"	5/8"	Pack of 100	0.3 lbs
SS38FW-100 Details & Purchase	3/8"	7/8"	Pack of 100	0.6 lbs
SS38FW-SM-100 Details & Purchase	3/8"	5/8"	Pack of 100	1 lb

Stainless Steel TEK Screws

SKU	Size	Qty.	Weight
ST1058 Details & Purchase	#10 x 5/8"	Pack of 500	2.55 lbs
ST1114 Details & Purchase	#10 x 1-1/4"	Pack of 100	0.05 lbs

Wedge Anchors

SKU	Size	Finish	Qty.	Weight
SWA382 Details & Purchase	3/8" x 2-3/4"	Stainless Steel	Each	0.45 lbs
SWA383 Details & Purchase	3/8" x 3-3/4"	Stainless Steel	Each	0.6 lbs
SWA123 Details & Purchase	1/2" x 3-3/4"	Stainless Steel	Each	1.1 lbs
SWA585 Details & Purchase	5/8" x 5"	Stainless Steel	Each	0.5 lbs
GWA123 Details & Purchase	1/2" x 3-3/4"	Galvanized	Each	1.1 lbs
GWA124 Details & Purchase	1/2" x 4-1/2"	Galvanized	Each	1.1 lbs
GWA125 Details & Purchase	1/2" x 5-1/2"	Galvanized	Each	1.1 lbs
GWA586 Details & Purchase	5/8" x 6"	Galvanized	Each	2.3 lbs

A325 Hex Bolts

SKU	Size	Grade	Thread Length	U of M	Weight
A1202 Details & Purchase	1/2" x 2"	A325	1"	Each	0.15 lbs
A5802 Details & Purchase	5/8" x 2"	A325	1-1/4"	Each	0.25 lbs
A582114 Details & Purchase	5/8" x 2-1/4"	A325	1-1/4"	Each	0.25 lbs
A582112 Details & Purchase	5/8" x 2-1/2"	A325	1-1/4"	Each	0.3 lbs
A58234 Details & Purchase	5/8" x 2-3/4"	A325	1-1/4"	Each	0.3 lbs
A34212 Details & Purchase	3/4" x 2-1/2"	A325	1-3/8"	Each	0.5 lbs

Grade 5 Hex Bolts

SKU	Size	Grade	Thread Length	U of M	Weight
G38114 Details & Purchase	3/8" x 1-1/4"	Grade 5	Full Thread	Each	0.05 lbs
G38112 Details & Purchase	3/8" x 1-1/2"	Grade 5	Full Thread	Each	0.05 lbs
G38212 Details & Purchase	3/8" x 2-1/2"	Grade 5	Full Thread	Each	0.1 lbs
G12112 Details & Purchase	1/2" x 1-1/2"	Grade 5	Full Thread	Each	0.1 lbs
G12112-B Details & Purchase	1/2" x 1-1/2"	Grade 5	Full Thread	175	19.5 lbs
G1202 Details & Purchase	1/2" x 2"	Grade 5	Full Thread	Each	0.15 lbs
G1203 Details & Purchase	1/2" x 3"	Grade 5	Full Thread	Each	0.2 lbs
G1204 Details & Purchase	1/2" x 4"	Grade 5	Full Thread	Each	0.2 lbs
G12045 Details & Purchase	1/2" x 4-1/2"	Grade 5	Full Thread	Each	0.25 lbs
G1205 Details & Purchase	1/2" x 5"	Grade 5	Full Thread	Each	0.25 lbs
G12065 Details & Purchase	1/2" x 6-1/2"	Grade 5	Full Thread	Each	0.35 lbs
G5802 Details & Purchase	5/8" x 2"	Grade 5	Full Thread	Each	0.2 lbs
G58134 Details & Purchase	5/8" x 1-3/4"	Grade 5	Full Thread	Each	0.2 lbs
G5806 Details & Purchase	5/8" x 6"	Grade 5	Full Thread	Each	0.75 lbs

Galvanized Heavy Hex Nuts

SKU	Size	Type	U of M	Weight
G38NUT Details & Purchase	3/8"	2H Heavy	Each	0.03 lbs
G12NUT Details & Purchase	1/2"	2H Heavy	Each	0.08 lbs
G12NUT-B Details & Purchase	1/2"	2H Heavy	500	25 lbs
G58NUT Details & Purchase	5/8"	2H Heavy	Each	0.1 lbs
A58NUT Details & Purchase	5/8"	2H Heavy	Each	0.1 lbs
G34NUT Details & Purchase	3/4"	2H Heavy	Each	0.2 lbs

Galvanized Lock Washers

SKU	Size	U of M	Weight
G38LW Details & Purchase	3/8"	Each	0.01 lbs
G12LW Details & Purchase	1/2"	Each	0.01 lbs
G12LW-B Details & Purchase	1/2"	1,000	15.25 lbs
G58LW Details & Purchase	5/8"	Each	0.05 lbs
G34LW Details & Purchase	3/4"	Each	0.05 lbs

Galvanized Flat Washers

SKU	Size	Type	U of M	Weight
G38FW Details & Purchase	3/8"	USS	Each	0.01 lbs
G12FW Details & Purchase	1/2"	USS	Each	0.01 lbs
G12FW-B Details & Purchase	1/2"	USS	500	19.2 lbs
G58FW Details & Purchase	5/8"	USS	Each	0.07 lbs
A58FW Details & Purchase	5/8"	USS	Each	0.05 lbs
G34FW Details & Purchase	3/4"	USS	Each	0.1 lbs

Galvanized Square Washers

SKU	Hole Size (nominal)	Size	U of M	Weight
SQW38 Details & Purchase	3/8"	1/4" x 2" x 2"	Each	0.25 lbs
SQW38-B Details & Purchase	3/8"	1/4" x 2" x 2"	150	38 lbs

Galvanized Backing Plates

SKU	Hole Size	Size	Qty.	Weight
BP4 Details & Purchase	3/4"	1/4" x 4" x 4"	Each	1.05 lbs

Select™ Screw Pin Shackles

SKU	Size	U of M	Weight
SHK14 Details & Purchase	1/4" (1/2 Ton)	Each	0.1 lbs
SHK38 Details & Purchase	3/8" (1 Ton)	Each	0.3 lbs

Post Caps

SKU	Size	Qty.	Weight
PC238 Details & Purchase	2-3/8" OD Pipe	Each	0.25 lbs
PC278 Details & Purchase	2-7/8" OD Pipe	Each	0.35 lbs
PC312 Details & Purchase	3-1/2" OD Pipe	Each	0.45 lbs
PC412 Details & Purchase	4-1/2" OD Pipe	Each	0.6 lbs

Hardware Kits

SKU	Screw Size	Qty.	Weight
SW75 Details & Purchase	3/8" x 3/4"	Pack of 10	0.6 lbs

Galvanized Pal Nuts

SKU	Size	U of M	Weight
G58PN Details & Purchase	5/8''	Individual	0.02 lbs

Climb Systems

Sector Frame Stand-Off Assembly

SKU	Description	Weight
115-359 Details & Purchase	Fits 1 1/2'' - 5'' OD rounds	5 lbs

Angle Stand-Off Assemblies

SKU	Type	Weight
120-123/317 Details & Purchase	Angles	1.1 lbs

Universal Angle and Round Leg Stand-Off Assemblies

SKU	Size	Weight
120-203/317 Details & Purchase	Round 1 1/2'' - 8'' Angle up to 6''	5.6 lbs

Cable Accessories

Hybrid Snap-In Hangers

SKU	Cable Size Range	Qty.	Weight
PSHS-1319-10 Details & Purchase	13 to 19 mm (1/2")	10 pack	0.89 lbs
PSHS-2630-10 Details & Purchase	26 to 30 mm (7/8")	10 pack	0.89 lbs
PSHS-3642-10 Details & Purchase	36 to 42 mm (1-1/4")	10 pack	2.08 lbs
PSHS-4852-10 Details & Purchase	48 to 52 mm (1-5/8")	10 pack	2.08 lbs

Cable Cushions

SKU	Cable Size Range	Hanger	Qty.	Color	Weight
PSCC-1001-10 Details & Purchase	4.5 to 6.5 mm	PSHS-1319-10	10 pack	Blue	0.3 lbs
PSCC-1002-10 Details & Purchase	6.6 to 8.5 mm	PSHS-1319-10	10 pack	Gray	0.29 lbs
PSCC-1003-10 Details & Purchase	8.6 to 10.5 mm	PSHS-1319-10	10 pack	Black	0.3 lbs
PSCC-2001-10 Details & Purchase	10.6 to 12.5 mm	PSHS-2630-10	10 pack	Orange	0.5 lbs
PSCC-2002-10 Details & Purchase	12.6 to 15.5 mm	PSHS-2630-10	10 pack	Black	0.5 lbs
PSCC-2003-10 Details & Purchase	15.6 to 17.5 mm	PSHS-2630-10	10 pack	Gray	0.4 lbs
PSCC-4001-10 Details & Purchase	19.6 to 30.3 mm	PSHS-4852-10	10 pack	Black	1.4 lbs

Universal Barrel Cushions

SKU	Cable Size Range	Hanger Size	Qty.	Weight
BCU114X Details & Purchase	14 mm to 25 mm	1-1/4"	10 pack	1 lb
BCU158X Details & Purchase	14 mm to 36 mm	1-5/8"	10 pack	1.3 lbs

Heavy-Duty Barrel Cushion

SKU	Cable Size Range	Hanger Size	Qty.	Weight
CIN38158 Details & Purchase	38 mm to 40 mm	1-5/8"	10 pack	1 lb

Cable Blocks

SKU	Cable Size & Type	Qty.	Weight
CXB4 Details & Purchase	Fiber Kit (4 to 6 mm)	10 pack	1.3 lbs
CXB14-2 Details & Purchase	1/4" cable (8 mm)	10 pack	0.2 lbs
CXB38 Details & Purchase	3/8" cable & Stranded 10mm & 3/8" Cable	10 pack	0.3 lbs
CXB12 Details & Purchase	1/2" Corrugated	10 pack	0.55 lbs
CXB78 Details & Purchase	7/8" Corrugated	10 pack	0.95 lbs
CXB114 Details & Purchase	1-1/4" Corrugated	10 pack	1.6 lbs
CXB158 Details & Purchase	1-5/8" Corrugated	10 pack	2.65 lbs

Galvanized 3/8" Angle Adapters

SKU	Qty.	Weight
GAP38 Details & Purchase	10 pack	4.7 lbs

Universal Nylon Angle Adapter

SKU	10 pack	Weight
PAA-U Details & Purchase	10 pack	1.1 lbs

Standoff Adapters

SKU	Description	Qty.	Weight
PSK Details & Purchase	Plastic Standoff Adapters	10 pack	8 lbs
SA1C Details & Purchase	Standoff Adapters	10 pack	0.3 lbs

Multi-Function Snap-In Adapter 1 Position

SKU	Description	Qty.	Weight
901044-10 Details & Purchase	PIM Shield Multi-Function Snap-In Adapter, 1 Position	10 pack	5.7 lbs

Multi-Function Snap-In Adapter 2 Position

SKU	Description	Qty.	Weight
901045-10 Details & Purchase	PIM Shield Multi-Function Snap-In Adapter, 2 Position	10 pack	9.1 lbs

Grounding

Pipe Ground Clamps

SKU	Pipe Range	Wire Range	Weight
KP-4 Details & Purchase	2-1/2" - 4"	10 Solid - 2 Stranded	1 lb

Ground Rods

SKU	Size	Weight
GR5880 Details & Purchase	5/8" x 8'	6 lbs

Ground Wire

SKU	Description	Spool Size	Weight
2T-100 Details & Purchase	2 AWG Green Tinned THHN	100'	25 lbs
2T-250 Details & Purchase	2 AWG Green Tinned THHN	250'	63 lbs
2G-100 Details & Purchase	2 AWG Green THHN	100'	29 lbs
2G-250 Details & Purchase	2 AWG Green THHN	250'	64 lbs

MG412U Ground Bars

SKU	Description	Weight
MG412U-K Details & Purchase	1/4" x 4" x 12" Ground Bar with Insulators and Brackets	5 lbs

MG418U Ground Bars

SKU	Description	Weight
MG418U-K Details & Purchase	1/4" x 4" x 18" Ground Bar with Insulators and Brackets	6.6 lbs

MG424U Ground Bars

SKU	Description	Weight
MG424U-K Details & Purchase	1/4" x 4" x 24" Ground Bar with Insulators and Brackets	8.7 lbs

MG210U Ground Bars

SKU	Description	Weight
MG210U Details & Purchase	1/4" x 2" x 10" Ground Bar	1.6 lbs
MG210U-K Details & Purchase	1/4" x 2" x 10" Ground Bar with Insulators and Brackets	3.2 lbs

Tapes, Chemicals, Banding

Plastic Round Member Adapters

SKU	Size Range	Qty.	Weight
PHC2-10 Details & Purchase	2" - 3"	10 pack	0.3 lbs
PHC3-10 Details & Purchase	3" - 4"	10 pack	0.4 lbs

Acetal Cable Tie

SKU	Description	Weight
TWR50 Details & Purchase	Acetal Cable Tie, 50' Reel	0.8 lbs
TWLH25 Details & Purchase	Acetal Cable Buckles, 25 pack	0.4 lbs

Tie Wraps

SKU	Description	Qty.	Weight
TW16 Details	16" Acetal Tie Wrap	50 pack	0.5 lbs
TW27 Details	27" Acetal Tie Wrap	25 pack	0.5 lbs

Banding Installation Tool

SKU	Description	Weight
ABIT Details	Acetal Banding Installation Tool	1 lb

PIM Mitigation

PIM Shield® Cable Support Bracket

SKU	Grip Range	Mounting Pipe Range	Material	Weight
009718-01-10 Details	1.25"	2.38" - 3.50" OD	Galvanized Steel	21.5 lbs
009718-02-10 Details	3.75"	2.38" - 3.50" OD	Galvanized Steel	22.9 lbs

PIM Foil

SKU	Description	Width	Length	Weight
900964-36-100 Details & Purchase	Standard Foil Roll	36"	100'	9 lbs

PIM Shield® Tape

SKU	Roll Width	Roll Length	Color	Weight
008587-12-25-B Details & Purchase	12 in	25 ft.	Black	15 lbs
008587-06-25-B Details & Purchase	6 in	25 ft.	Black	7.5 lbs
008587-06-25-W Details & Purchase	6 in	25 ft.	White	7.5 lbs

PIM Shield® Mitigation Paint

SKU	Size	Qty. Per Case	Weight
901087-1-PKG Details	1 Gallon	1	10.5 lbs
901087-5 Details	5 Gallon	1	55 lbs

Misc

SKU	Weight
MEP1012-6LHS2C Details	3,999 lbs
SP1-MSK4 Details & Purchase	98 lbs
SP1-MSK9 Details	7 lbs
CH240 Details	7 lbs
ACOVR1010B-HDR Details	1,430 lbs
MEP1015-TMO1-K Details	4,243 lbs
LPCA-A Details	0 lbs
LPC619-B Details	0 lbs
LPC6-A Details	0 lbs
SP1-SFK3SL Details	120 lbs
SP1-SFK1 Details	95 lbs
SNP-10XS-396 Details	1,761 lbs
MEP810-6S Details	0 lbs
MEP1015-7SSSRC Details	4,320.54 lbs
RP1010 Details	33 lbs
MEP1020-7SSSRC Details & Purchase	5,329.04 lbs
MEP1020-7SSS1 Details & Purchase	2,889.41 lbs
MEP1015-7SSS1 Details & Purchase	2,200.99 lbs
MEP1010-7SSSR Details & Purchase	2,212.91 lbs
SCGB-RM Details & Purchase	4 lbs
MEP1010-7SSS1 Details & Purchase	1,524.04 lbs
RMVD8-3-3096 Details & Purchase	2,172 lbs
MEP1012-6LHS1C Details & Purchase	3,872 lbs
SP1-MSK8 Details & Purchase	37 lbs
VFA12-HD-TM1 Details & Purchase	650 lbs
MEP812-8SH40S1C Details	1,692 lbs
VFA10-HD-80F Details	631 lbs
RMQP-40126-HK Details & Purchase	3,003 lbs
